4.3.1 Create Analog Trunks

Analog trunk is associated with FXO port, and it will call outside by PSTN line. Click on New
Analog Trunk , then we can see the parameters which are in the following table in the web.
Name Description
Channels Display the FXO or GSM modules
Trunk Name The name you want to set for the trunk
Busy Detection Busy detection is used to detect far end hang
up or for detecting busy signal.
busycount If Busy Detection is enabled,it is also possible
to specify how many busy tones to wait for
before hanging up.
Ring Timeout Thrunk(FXO) devices must have a timeout
to determine if there was a hangup before the
line was answered.
answeronpolarit If this option is enabled, the reception of a
yswitch polarity reversal will mark when a outgoing
call is answered by the remote party.
hanguponpolarit In some countries ,a polarity reversal is used
yswitch to single the disconnect of a phone line.
Use CallerID Enabling this option enabled CallerId
detection.
Caller ID Start This option allows one to define the start of a
CallerID Signal.
CallerID This option allows the lines to report the
Caller ID string as received from the telco, or
as a fixed value by using the custom option.
Pulse Dial If this option is enabled ,pulse mode dialing
instead of DTMF,wil be enable.
CID Signalling This option defines the type of caller ID
signaling to use :bell,v23,v23_jp,or dtmf.
Flash Timing Flash Time defines the time ,in
millseconds,that is generated for a flash
operation.
Receive Flash Flash Time defines the time,in milliseconds,
Timing that is generated for a flash operation.
www.atcom.cn
Type Default
selected no select
Textbox null
Boolean
Yes
Int 3
Int 8000
Boolean
no
Boolean
no
Boolean yes
ComboBox Ring
select box As Received
Boolean No
ComboBox Bell-USA
Textbox
750
Textbox
1250
