Socket CF RFID Reader Card User Manual page 47

I·Code SLI ISO15693 (Philips)
The complete I·Code SLI specification can be found in the Philips publication titled
"I·Code SLI Smart Label IC SL2 ICS20 Functional Specification".
Figure 1 - Memory Structure of the I·Code SLI (version SL2 ICS20)
896 bits (112 bytes) of user memory is available for read/write.
Block #
0 (0x00)
1 (0x01)
2 (0x02)
.
.
.
26 (0x1A)
27 (0x1B)
A 64-bit ID (factory programmed) uniquely identifies each I·Code SLI chip (SL2 ICS20).
TID
my-d SRF55VxxP ISO15693 (Infineon)
The complete my-d SRF55VxxP specification can be obtained from Infineon.
Figure 2 - Memory Structure of the my-d SRF55V02P
29 blocks of 8 bytes = 232 bytes (1856 bits) of user memory is available for read/write.
Block #
3 (0x03)
4 (0x04)
5 (0x05)
.
.
.
30 (0x1E)
31 (0x1F)
APPENDIX B: HF RFID STANDARDS AND TAG DESCRIPTIONS
32 bits
(4 bytes per block)
. .
. .
. .
0xE0 0x04
64 bits
(8 bytes per block)
. . . .
. . . .
. . . .
The user can permanently
lock any block.
. .
. .
Once a block is locked it can
. .
not be unlocked.
0x01 Unique Tag ID 40 bits (5 bytes)
. . .
. . .
. . .
The user can
permanently lock
any block
.
Once a block is
locked it can not
.
be unlocked.
.
