Enable Inventory and Loop Modes

The CF RFID Reader Card has four reading modes, based on different
combinations of inventory mode and loop mode. The chart below shows the results
of enabling or disabling the modes.
Tag Select Loop
Mode Mode
One tag Disabled
One tag
Enabled
continuously
All tags
Disabled
present
All tags
Enabled
continuously
Note: Not all tag types are readable in Inventory Mode.
1. In the main screen of RFID Demo, tap RFID at the bottom of the screen. In the
pop-up menu, select adjust the Inventory Mode and/or Loop Mode settings as
desired.
2. After selecting the desired settings, tap Select Tags. The CF RFID Reader
Card will search for tags in range, according to your settings.
CHAPTER 5: RFID DEMO
Inventory
Description
Mode
Disabled Selects the first tag in RF field
Selects the first tag continuously (the same tag ID will
Disabled
be returned as long as the tag remains in the RF field.
Inventory mode: returns the tag IDs of all tags in the
Enabled RF field and then reports when there are no more
tags.
Returns the tag IDs of all tags in the RF field. It does
Enabled not repeat a tag ID unless the tag goes out and then
re-enters the RF field.
