8.6 Display Mode Set Up (Cont.)
(2) Press the "DOWN" button three (3) times so that the cursor is now flashing over the
# 4 "DISPLAY MODE." option. The LCD will display the following with the cursor box
now flashing over the # 4 option.
(3) Press the "Record" button to enter the DISPLAY MODE option. The LCD will display
the following:
(4) Use the "UP" or "DOWN" button to change the mode from 255 to 100 or vice versa.
(5) Once changed, press the "RECORD" button to confirm and store your new setting.
(6) Press the "ESC" button two (2) times to exit.

8.7 MIDI Channel Set Up

These settings only need to be set if you are linking a MIDI device to DMX Operator Pro's MIDI
input. The MIDI channel set up option allows you to set the desired Midi channel into the DMX
Operator Pro.
(1) Press and hold down the "SETUP" button for three (3) seconds or until the green
LED above the SETUP button comes on. The LCD will display the following with a
cursor box flashing over the # 1 option.
3. P/T FADE ONLY
4
. DISPLAY MODE
DISPLAY MODE:255
OK ESC SEL ADJ
1
. CF CARD
2. ASSIGN CH.
DMX OPERATOR PRO
↓
35
