Elation DMX OPERATOR PRO User Manual page 11

7.2 Assign Joystick to Pan & Tilt (Cont.)
(4) Press the "UP" button sixteen (16) times or until your LCD display reads "PAN
>NONE" on the top line as displayed below.
(5) Next, press the "DOWN" button until the LCD display's the Pan channel # for your
fixture. You will have to refer to the DMX chart that came with your light to input this
information. For example, if the Pan channel of your light is channel # 1, then you
would set your controller up as displayed below.
(6) Press the "UP" button one (1) time so that your LCD display's "TILT >NONE" on the
top line as displayed below.
(7) Next, press the "DOWN" button until the LCD display's the tilt channel # for your
fixture. Once again, please refer to the DMX chart that came with your light for this
information. For example, if the Tilt channel of your light is channel # 2, then you
would set your controller up as displayed below.
(8) If your lights incorporate Pan Fine and Tilt Fine channels, repeat steps 4 thru 7.
(9) Next, press and hold down the "GROUP" button and simultaneously select
the "FIXTURE" number buttons to select the lights you wish to assign the
joystick to. All selected fixtures will have the LED above the buttons flashing.
PAN >NONE
OK ESC SEL ADJ
PAN >CH01
OK ESC SEL ADJ
TILT >NONE
OK ESC SEL ADJ
TILT >CH02
OK ESC SEL ADJ
DMX OPERATOR PRO
11
