7.1.2 Setting DMX Address Channels for Dimmer Packs (Par Cans)

There is no fixture library incorporated into this console. There are eight DMX channels reserved
for par cans which will be independently controlled via eight faders. These eight DMX channels
were designed to be assigned to two four channel dimmer packs. However, you may assign them
as you like as long as they fall within the reserved DMX channels of 129 to 136. To set two four
channel dimmer packs, follow these steps:
(1) Set the starting DMX address channel on your first dimmer pack to (129)- dip switches 1
& 8 ON.
(2) Set the DMX channel on your second dimmer pack to (133)- dip switches 1,3 & 8 ON. .
7.2 Assign Joystick to Pan & Tilt
(1) Press and hold down the "SETUP" button for three (3) seconds or until the green
LED above the SETUP button comes on. The LCD will display the following with a
cursor box flashing over the # 1 option.
(2) Press the "DOWN" button one (1) time so that the cursor is now flashing over the # 2
"ASSIGN CH." option. The LCD will display the following with the cursor box now
flashing over the # 2 option.
(3) Press the "Record" button to enter the assign channel option. The LCD will display
the following:
1
. CF CARD
2. ASSIGN CH.
↓
1. CF CARD
2
. ASSIGN CH.
CHANNEL01>OUT01
OK ESC SEL ADJ
DMX OPERATOR PRO
↓
10
