8.4 Channel Patch

(1) Press and hold down the "SETUP" button for three (3) seconds or until the green
LED above the SETUP button comes on. The LCD will display the following with a
cursor box flashing over the # 1 option.
(2) Press the "DOWN" button one (1) time so that the cursor is now flashing over the # 2
"ASSIGN CH." option. The LCD will display the following with the cursor box now
flashing over the # 2 option.
(3) Press the "Record" button to enter the assign channel option. The LCD will display
the following:
(4) Use the "UP" button to scroll through the 16 channels and use the "DOWN" button to
change the corresponding fader output. For example, if I want channel # 1 to be
controlled by fader # 7 on the console, the LCD will display the following:
(5) Repeat step 4 until you have patched all desired channels.
1
. CF CARD
2. ASSIGN CH.
↓
1. CF CARD
2
. ASSIGN CH.
CHANNEL01>OUT01
OK ESC SEL ADJ
CHANNEL01>OUT07
OK ESC SEL ADJ
DMX OPERATOR PRO
↓
