Registering stations and PA outputs to zones
[System setting – Zone setting]
Assign stations and PA outputs to the registered zones.
1 Click Zone setting in the table of contents.
2
Select a zone from the pull-down menu.
3
Click to display all the registered stations
Reference
in your site.
Another window opens and the registered stations are
displayed in the list.
4 Check to select the target stations.
Select stations in the following ways.
• Select stations by checking one by one.
•
All stations of the same type can be selected by
clicking the corresponding button under [Select all by
type].
•
By clicking the button for the control unit, all the
stations connected to it are checked or canceled.
• By clicking the button on the top of the list, all the
stations are checked or canceled.
5
Click after you have fi nished selecting the
Close
stations.
In the previous window, the selection results are displayed
in the list.
When canceling a registered station, check the station in
*
the list, then click Delete .
* Register PA outputs in the same way as the stations.
6
Click
Temporarily stored
results temporarily.
If you wish to cancel the setting results you have made,
*
click a title in the table of contents or "Refresh" in the
web browser menu.
to save the current setting

Registering sound sequences

[Chime setting – Registering sound sequences]
Register sound sequences for chime.
Up to 20 sequences can be registered.
*
1
Click Registering sound sequences in the table of
contents.
2 [Sound sequence number]:
Select the sound sequence number to register a sound
sequence from the pull-down menu.
3 [Sound sequence name]:
Enter the name of sound sequence.
4
Click to add sound fi les to the sound sequence.
Add
Another window appears.
5 [Step]:
Select an unused step number from the pull-down menu.
If the selected step number is already used, it can be set
*
with a new sound source and the old and subsequent
ones are renumbered with the following numbers.
If an unused number exists before the number you
*
selected, the unused number is re-selected automatically.
Up to 10 steps can be used.
*
6
[Sound source]:
Select a sound fi le from the registered ones and set the
repeating time (from 1 to 10) of the sound.
7 When you have fi nished the setting on this window,
click .
Close
In the previous window, the registered sound fi les are
displayed in the list.
8 Repeat step 2 to 7 to register more sound sequences.
Other buttons
• Edit
If you wish to modify, check the fi le in the list, and then
click Edit .
Delete
•
When deleting an added sound fi le, check the fi le in the
list, and then click Delete .
9
Click
Temporarily stored
results temporarily.
If you wish to cancel the setting results you have made,
*
click a title in the table of contents or "Refresh" in the
web browser menu.
NOTE:
It is required to register sound source(s) on the IS-CCU connected to
the IS-IPC (as the IP host unit) directly before making this setting.
(→P. 36)
to save the current setting
