STARTING UP THE SYSTEM AND PREPARING FOR THE SETTINGS

The system settings are mainly made on the PC by accessing the web browser for the settings incorporated with the IP control unit
(IS-IPC) as the IP host unit. It is recommended to use only one PC for the settings that is connected to the system.

System requirements for PC

Your PC and operating environment must meet the following system requirements to make the settings.
Network
Web browser

Starting up the system

1
Connect a PC to the IP control unit.
[When connecting a PC to the IP control unit via
a hub (switch)]
RJ45
CAT5e/6
100m (330')
(Straight-through cable)
10BASE-T/
100BASE-TX
RJ45
NOTES:
Be sure to connect the CAT5e/6 cable to the LAN ports of both
•
units.
The IP address of IP control unit is set to (192.168.0.40) and
•
Subnet Mask is set to (255.255.255.0) as default. Change the
IP address of your PC if needed.
16
10BASE-T Ethernet, 100BASE-TX Ethernet
Internet Explorer 6.0 or later (with Internet Options SSL 3.0 enabled)
RJ45
Hub
(Switch)
CAT5e/6
100m (330')
(Straight-through
10BASE-T/
cable)
100BASE-TX
RJ45
PC
[When connecting a PC to the IP control unit
directly]
CAT5e/6 (Crossover cable)
100m (330')
10BASE-T/100BASE-TX
NOTES:
• When connecting a PC to the IP control unit directly, use an
Ethernet crossover cable.
The IP address of IP control unit is set to (192.168.0.40) and
•
Subnet Mask is set to (255.255.255.0) as default. Change the
IP address of your PC if needed.
PC
RJ45
(Continued on next page)
