Aiphone Standard (IP) System Setting Manual page 6

Title Sub title
System setting Area/Site
registration
Zone registration
IP unit registration Station type
Control units
composition
Registering
stations
Advanced station
settings
6
Item
Area/Site Name -
Area/Site -
IP Address (sites -
only)
Port number (sites -
only)
Connection -
Password (sites only)
Door release (sites -
only)
Zone name -
-
MAC address -
Unit name -
Port number -
(Depends on -
the system
confi guration.)
Area (stations only) -
Station number -
(stations only)
Station name -
(for stations)
Station name -
(for PA output)
(Required when
an external unit is
connected to the
corresponding PA
output terminals)
Station type -
(sub stations only)
Video door
station/Audio
door station/
Room sub
station
Sub item
Up to 24 alphanumeric characters (for
up to 99 areas including sites)
* Up to 31 for sites
Area/Site
0 - 255 (for each fi eld)
1024 - 65535
Up to 16 alphanumeric characters
ON/OFF
Up to 24 alphanumeric characters (for
up to 99 zones)
IP control unit, IP video door station, IP
master station, PC master station
-
Up to 24 alphanumeric characters
1024 - 65535
Connected/Not connected
(Area) 01 to 99
001 to 999
0001 to 9999
00001 to 99999
Up to 24 alphanumeric characters
Up to 24 alphanumeric characters
(Select from the registered ones.)
Call priority Normal/Priority/Urgent
Called stations (Set up to 20 targets from the registered
ones.)
Contact type Normally open (NO)
/Normally closed (NC)
Call priority/Answering Answering the page
the page /Call (Normal/Priority/Urgent)
Transmit volume boost ON/OFF
at PTT (ON: approx. +6dB up)
Camera zoom image 0 (wide)/1/2/3/4/5/6/7/8/9 (zoom)
preset (video door
stations only)
Call acknowledge tone ON/OFF
on/off
Backlight adjustment Exposure +/Exposure -
(video door stations
only)
Speaker Built-in speaker
(room sub stations /External speaker
only)
Setting range
1 (for Area
number 01)
Area
-
-
-
ON
-
-
-
-
IP control unit:
50900 - 50906
IP station:
50900 - 50902
Not connected
(Area) 01
-
-
-
(Depends on
the control
unit.)
Normal
-
Normally open
(NO)
Normal
OFF
5 (Center)
ON
Exposure +
Built-in
speaker
Default
