Flow 2 - Aiphone Standard (IP) System Setting Manual

Flow 2

(All units: Static IP addresses are set)
* This is the outline of setting fl ow. Also make the detailed settings on each setting window referring to the corresponding pages.
START
Write down the MAC addresses of all the IP units to be
used in the system in advance by using the "Setting
Information Memo" (→P. 38) etc.
The MAC address is labeled on each unit.
*
Decide the static IP address for each IP unit.
Make the [Network setting: Individual] settings on each
IP unit individually. (→ P. 19)
Connect the units and the PC used for settings to the
network, and then turn them on respectively.
Confi rm the [Network setting: Common] settings on the
IP host unit. (→ P. 19)
Confi rm that the multicast addresses and/or port
*
numbers do not overlap those of other manufacturer's
network devices connected to the same network.
Add IP units you will use in the system at [IP unit
registration] on the IP host unit. (→ P. 22)
(The selected unit is added in the list whenever selected.)
If you will connect your site with remote sites, make the
remote site connection settings. (→ P. 15)
Make the other system settings. (→ P. 20-36)
For the IP host unit
Connect the IP host unit and the PC used for settings
directly, and then turn them on. After a while, access
"https://192.168.0.40/" from the browser on the PC.
(→P. 17)
NOTES:
When connecting a PC to the IP unit directly, use an
•
Ethernet crossover cable.
If a warning dialog box for security or guarding against virus
•
programs appears when accessing the web browser, give permission.
Make the [Network setting: Individual] settings on the
IP host unit. (→ P. 19)
Set it as "Host unit".
*
Set the static IP address to the IP host unit.
*
Update the system at [Updating the system]. (→ P. 35)
For each IP client unit
Connect an IP client unit and the PC used for settings
directly, and then turn them on. After a while, access
"https://192.168.0.40/" from the browser on the PC.
(→P. 17)
NOTES:
When connecting a PC to the IP unit directly, use an
•
Ethernet crossover cable.
If a warning dialog box for security or guarding against virus
•
programs appears when accessing the web browser, give permission.
Make the [Network setting: Individual] settings on the
IP client unit. (→ P. 19)
Set it as "Client unit".
*
Enter the IP address of the IP host unit.
*
Set the static IP address to the IP client unit.
*
Update the system at [Updating the system]. (→ P. 35)
: Settings on the IP host unit
: Settings on the IP client units
(Log in.)
(Log in.)
