Page 1
Report Number: B30804208-E August 12, 2003 EMC COMPLIANCE TEST REPORT LCD Monitor Trade Name Compal Model Number EM989 Serial Number Report Number B30804208-E Date August 12, 2003 Regulations See below Standards Results (Pass/Fail) EN 55022: 1998 + A1: 2000 PASS...
Page 2
EC-Declaration of Conformity For the following equipment: LCD Monitor Product Name ) EM989 / Compal ( Model Designation / Trade Name ) Compal Electronics (China) Co., Ltd. ( Manufacturer Name ) No. 988, Tung Fen East Rd., Economic & Technical Development Zone Kunshan, Jiangsun, P.R. China...
Report Number: B30804208-E August 12, 2003 TABLE OF CONTENTS VERIFICATION OF COMPLIANCE ..........................4 GENERAL INFORMATION ...............................5 SYSTEM DESCRIPTION ..............................6 PRODUCT INFORMATION ...............................7 SUPPORT EQUIPMENT ..............................8 TEST FACILITY ..................................9 TEST EQUIPMENT LIST (EMISSION) ........................10 TEST EQUIPMENT LIST (IMMUMITY) ........................11 SECTION 1 EN 55022 (LINE CONDUCTED & RADIATED EMISSION) ..........12 MEASUREMENT PROCEDURE (PRELIMINARY LINE CONDUCTED EMISSION TEST) .....12...
Kunshan, Jiangsun, P.R. China B30804208-E File Number: Date of Test: August 5 ~ 12, 2003 Equipment Under Test: LCD Monitor EM989 Model Number: Serial Number: Type of Test: EMC Directive 89/336/EEC for CE Marking Technical Standards: EN 55022: 1998 + A1: 2000...
Report Number: B30804208-E August 12, 2003 3 SYSTEM DESCRIPTION EUT Test Program: 1. EMI test program was loaded and executed in Windows 2000 mode. 2. Data was sent to EUT filling the screen with upper case of “H” patterns. 3. Test program sequentially exercised printer and modem, then sent “H” patterns to them individually.
Report Number: B30804208-E August 12, 2003 4 PRODUCT INFORMATION Housing Type: Plastic EUT Power Rating: 100-240VAC, 50/60Hz, 1.2A AC power during Test: 230VAC/50Hz AC Power Cord Type: Unshielded, 1.8m (Non-detachable) OSC/Clock Frequencies¡ G 12MHz Power Board Manufacturer: Compal Model: VP-908 Main Board Manufacturer: Compal Model: VL-720...
Report Number: B30804208-E August 12, 2003 6 TEST FACILITY Location: No. 81-1, 210 Lane, Pa-de 2 Road, Lu-Chu Hsiang, Taoyuan, Taiwan, R. O. C. Description: There are four 3/10m open area test sites and three line conducted labs for final test. The Open Area Test Sites and the Line Conducted labs are constructed and calibrated to meet the FCC requirements in documents ANSI C63.4: 1992 and CISPR 16 requirements.
Report Number: B30804208-E August 12, 2003 7 TEST EQUIPMENT LIST (EMISSION) Instrumentation: The following list contains equipment used at C & C Laboratory, Co., Ltd. for testing. The equipment conforms to the CISPR 16-1 / ANSI C63.2-1988 Specifications for Electromagnetic Interference and Field Strength Instrumentation from 9kHz to 1.0 / 2.0 GHz. Equipment used during the tests: Open Area Test Site: Open Area Test Site # 1...
Report Number: B30804208-E August 12, 2003 8 TEST EQUIPMENT LIST (IMMUMITY) ESD test (61000-4-2) EQUIPMENT MODEL SERIAL LAST CAL DUE. TYPE NUMBER NUMBER CAL. ESD Generator EM TEST P30C 0603-01 02/27/2003 02/26/2004 Radiated Electromagnetic Field immunity Measurement (61000-4-3) EQUIPMENT MODEL SERIAL LAST CAL DUE.
Report Number: B30804208-E August 12, 2003 SECTION 1 EN 55022 (LINE CONDUCTED & RADIATED EMISSION) MEASUREMENT PROCEDURE (PRELIMINARY LINE CONDUCTED EMISSION TEST) 1) The equipment was set up as per the test configuration to simulate typical actual usage per the user’s manual.
Page 13
Report Number: B30804208-E August 12, 2003 MEASUREMENT PROCEDURE (FINAL LINE CONDUCTED EMISSION TEST) 1) EUT and support equipment was set up on the test bench as per step 10 of the preliminary test. 2) A scan was taken on both power lines, Line 1 and Line 2, recording at least the six highest emissions.
Report Number: B30804208-E August 12, 2003 9.2 MEASUREMENT PROCEDURE (PRELIMINARY RADIATED EMISSION TEST) 1) The equipment was set up as per the test configuration to simulate typical actual usage per the user’s manual. When the EUT is a tabletop system, a wooden turntable with a height of 0.8 meters is used which is placed on the ground plane as per EN 55022 (see Test Facility for the dimensions of the ground plane used).
Page 15
Report Number: B30804208-E August 12, 2003 MEASUREMENT PROCEDURE (FINAL RADIATED EMISSION TEST) 1) EUT and support equipment were set up on the turntable as per step 8 of the preliminary test. 2) The Analyzer / Receiver scanned from 30MHz to 1000MHz. Emissions were scanned and measured rotating the EUT to 360 degrees, varying cable placement and positioning the antenna 1 to 4 meters above the ground plane, in both the vertical and the horizontal polarization, to maximize the emission reading level.
August 12, 2003 10 BLOCK DIAGRAM OF TEST SETUP System Diagram of Connections between EUT and Simulators EUT: LCD Monitor Trade Name: Compal Model Number: EM989 Power Cord: Unshielded, 1.8m DVI Cable x 1 VGA Cable x 1 Audio Cable x 1 LCD Monitor 1.
Page 17
Report Number: B30804208-E August 12, 2003 (For Harmonic & Flicker Test Only) DVI Cable x 1 VGA Cable x 1 Audio Cable x 1 LCD Monitor 1. PC (EUT) 2. Modem 3. Printer 4. PS/2 5. PS/2 Mouse Keyboard Page 17 Rev.
Report Number: B30804208-E August 12, 2003 11 SUMMARY DATA (LINE CONDUCTED TEST) Model Number: EM989 Location: Site # 3 Tested by: George Kuo Test Mode: Mode 3 Test Results: Passed Temperature: 26 Humidity: 64%RH (The chart below shows the highest readings taken from the final data) FREQ Q.P.
Page 19
Report Number: B30804208-E August 12, 2003 SUMMARY DATA (RADIATED EMISSION TEST) Model Number: EM989 Location: Site # 1 Tested by: George Kuo Polar: Vertical--10m Test Mode: Mode 3 Test Results: Passed Detector Function: Quasi-Peak Temperature: 30 Humidity: 62%RH (The chart below shows the highest readings taken from the final data) ================================================================= Freq.
Page 20
Report Number: B30804208-E August 12, 2003 SUMMARY DATA (RADIATED EMISSION TEST) Model Number: EM989 Location: Site # 1 Tested by: George Kuo Polar: Horizontal --10m Test Mode: Mode 3 Test Results: Passed Detector Function: Quasi-Peak Temperature: 30 Humidity: 62%RH (The chart below shows the highest readings taken from the final data) ================================================================= Freq.
Report Number: B30804208-E August 12, 2003 12 SECTION 2 EN 61000-3-2 & EN 61000-3-3 (POWER HARMONICS & VOLTAGE FLUCTUATION / FLICKER) POWER HARMONICS MEASUREMENT Port : AC mains Basic Standard : EN 61000-3-2 (2000) Limits CLASS A ; CLASS D Tester : Stanley Huang Temperature...
Report Number: B30804208-E August 12, 2003 Test Procedure: 1. The EUT was located 0.1 m minimum from all side of the HCP. 2. The indirect support units were located 1 m minimum away from the EUT, but direct support unit was/were located at same location as EUT on the HCP and keep at a distance of 10 cm with EUT.
Page 26
Report Number: B30804208-E August 12, 2003 The Tested Points of EUT (Photo 1 of 3) (Photo 2 of 3) Page 26 Rev. 00...
Page 27
Report Number: B30804208-E August 12, 2003 (Photo 3 of 3) Page 27 Rev. 00...
Report Number: B30804208-E August 12, 2003 14 SECTION 4 IEC 61000-4-3 (RADIATED ELECTROMAGNETIC FIELD) RADIATED ELECTROMAGNETIC FIELD IMMUNITY TEST Port : Enclosure Basic Standard : IEC 61000-4-3 Requirements : 3 V/m / with 80% AM. 1kHz Modulation. Performance Criteria : A (Standard Require) Tester : George Kuo Temperature...
Page 29
Report Number: B30804208-E August 12, 2003 Test Procedure: 1. The EUT was located at the edge of supporting table keep 3 meter away from transmitting antenna, it just the calibrated square area of field uniformity. The support units were located outside of the uniformity area, but the cable(s) connected with EUT were exposed to the calibrated field as per IEC 61000-4-3.
Page 30
Report Number: B30804208-E August 12, 2003 Performance & Result: Criteria A: The apparatus continues to operate as intended. No degradation of performance or loss of function is allowed below a performance level specified by the manufacturer, when the apparatus is used as intended. In some cases the performance level may be replaced by a permissible loss of performance.
Report Number: B30804208-E August 12, 2003 15 SECTION 5 IEC 61000-4-4 (FAST TRANSIENTS/BURST) FAST TRANSIENTS/BURST IMMUNITY TEST Port : On Power Supply Lines Basic Standard : IEC 61000-4-4 : ± 1 kV for Power Supply Line Requirements Performance Criteria : B (Standard Require) Tester : George Kuo Temperature...
Page 32
Report Number: B30804208-E August 12, 2003 Test Procedure: 1. The EUT and support units were located on a wooden table 0.8 m away from ground reference plane. 2. A 1.0 meter long power cord was attached to EUT during the test. 3.
Report Number: B30804208-E August 12, 2003 16 SECTION 6 IEC 61000-4-5 (SURGE IMMUNITY) SURGE IMMUNITY TEST Port : Power Cord Basic Standard : IEC 61000-4-5 : ± 1 kV (Line to Line) Requirements ± 2 kV (Line to Ground) Performance Criteria : B (Standard Require) Tester : George Kuo Temperature...
Page 34
Report Number: B30804208-E August 12, 2003 Test Procedure: 1. The EUT and support units were located on a wooden table 0.8 m away from ground floor. 2. A test program was loaded and executed in Windows 2000 mode. 3. The data was sent to EUT filling the screens with upper case of “H” patterns. 4.
Report Number: B30804208-E August 12, 2003 17 SECTION 7 IEC 61000-4-6 (CONDUCTED DISTRBANCE/INDUCED RADIO-FREQUENCY FIELD) CONDUCTED DISTRBANCE/INDUCED RADIO-FREQUENCY FIELD IMMUNITY TEST Port : AC Port Basic Standard : IEC 61000-4-6 Requirements : 3 V / with 80% AM. 1kHz Modulation. Injection Method : CDN-M3 Performance Criteria : A (Standard Require)
Page 36
Report Number: B30804208-E August 12, 2003 Test Procedure: 1. The EUT and support units were located at a ground reference plane with the interposition of a 0.1 m thickness insulating support and the CDN was located on GRP directly. 2. A ‘H’ messages were displayed on screen of EUT. 3.
Report Number: B30804208-E August 12, 2003 18 SECTION 8 IEC 61000-4-8 (POWER FREQUENCY MAGNETIC FIELD IMMUNITY TEST) POWER FREQUENCY MAGNETIC FIELD IMMUNITY TEST Port : Enclosure Basic Standard : IEC 61000-4-8 Requirements : 1 A/m Performance Criteria : A (Standard Require) Tester : George Kuo Temperature...
Page 38
Report Number: B30804208-E August 12, 2003 Test Procedure: 1. The EUT and support units were located on Ground Reference Plane with the interposition of a 0.1 m thickness insulation support. 2. Putting the induction coil on horizontal direction. ( X direction ) 3.
Report Number: B30804208-E August 12, 2003 19 SECTION 9 IEC 61000-4-11 (VOLTAGE DIPS, SHORT INTERRUPTIONS AND VOLTAGE VARIATIONS) VOLTAGE DIPS / SHORT INTERRUPTIONS Port : AC mains Basic Standard : IEC 61000-4-11 (1994) Requirement : PHASE ANGLE 0, 45, 90, 135, 180, 225, 270, 315 degrees Test Level Reduction Duration...
Page 40
Report Number: B30804208-E August 12, 2003 Test Procedure: 1. The EUT and support units were located on a wooden table, 0.8 m away from ground floor. 2. A test program was loaded and executed in Windows 2000 mode. 3. The data was sent to EUT filling the screens with upper case of “H” patterns. 4.
