AG Neovo ER-191 Test Report

Hide thumbs

Advertisement

Quick Links

Download this manual
IEC SYSTEM FOR MUTUAL RECOGNITION OF TEST CERTIFICATES
FOR ELECTRICAL EQUIPMENT (IECEE) CB SCHEME
Issued by:
Product:
Applicant:
Manufacturer:
Factory:
nb: Additional factory
information on page 2
Rating and principal
characteristics:
Trade mark (if any):
Model/Type
reference:
Additional information:
Sample of product
tested to be in
conformity with IEC:
Test Report Ref. No:
This CB Test Certificate is issued by the National Certification Body:
TÜV SÜD PSB Pte Ltd
1 Science Park Drive, Singapore 118221
Signed by:
Teo Kim Hock
Date of issue:
2007-11-26
CB TEST
CERTIFICATE
TÜV SÜD PSB Pte Ltd
LCD Monitor
DIVA Laboratories Ltd. 7TH FL-8, 351 CHUNG
DIVA Laboratories
Ltd.
DIVA Laboratories Ltd. 7TH FL-8, 351 CHUNG
100-240V~, 50/60Hz, 1.2-0.6A, Class I
DIVA
GODx7yzMI and GOKx7yzMI (where x = 8 or 9, y = 0-9 or A-Z and z = A-Z)
Certificate SG-2499 issued 2006-08-07 and Certificate SG-2499M1 issued
2006-10-25 are replaced by this version due to add model, trademark,
alternate metal enclosure and base and alternate classification according to
the degree of protection against ingress of water.
60601-1(ed.2);am1;am2
55S072147/NCH/CZ
SHAN RD, SEC 2,
CHUNG HO, TAIPEI
HSIEN 235 TAIWAN
7TH FL-8, 351 CHUNG
SHAN RD, SEC 2,
CHUNG HO, TAIPEI
HSIEN 235 TAIWAN
SHAN RD, SEC 2,
CHUNG HO, TAIPEI
HSIEN 235 TAIWAN
Ref. Certificate No.
SG-2499M2
Taiwan
Taiwan
Taiwan
1/2
