Summary of Contents for AG Neovo E Series

  • Page 2: Table Of Contents

    GM998 TFT LCD MONITOR CONTENTS 1. INTRODUCTION ............................2 1.1 Scope ..................................2 1.2 Description ................................2 2. ELECTRICAL REQUIREMENTS......................... 3 2.1 Standard Test Conditions ............................. 3 2.2 LCD monitor General specification........................4 2.3 LCD panel specification ............................5 2.4 Input Signals............................... 13 2.5 CONTROLS ................................

  • Page 3: Introduction

    1. INTRODUCTION 1.1 Scope This specification defines the requirements for the 19” MICRO-PROCESSOR based Multi- mode supported high resolution color LCD monitor. This monitor can be directly connected to general 15 pin D-sub VGA connector and DVI-D digital connector, eliminates the requirement of optional special display card.

  • Page 4: Electrical Requirements

    2. ELECTRICAL REQUIREMENTS 2.1 Standard Test Conditions All tests shall be performed under the following conditions, unless otherwise specified. Ambient light 225 lux Viewing distance : 50 cm in front of LCD panel Warrn up time All specifications : 30 minutes Fully functional : 5 seconds Measuring Equipment :...

  • Page 5: Lcd Monitor General Specification

    2.2 LCD monitor General specification 19 “ active matrix color TFT LCD Panel Type : 1). FUJITSU FLC48SXC8V-10 376.32mm(H) x 301.056mm(V) Display size : To see timing table Display mode : 0.098x3mm(H) x 0.294mm(V) Pixel pitch : 1280 x (RGB) x 1024 Display Dot : 25.2 –...

  • Page 6: Lcd Panel Specification

    2.3 LCD panel specification GL999-E01...
  • Page 7 GL999-E02...
  • Page 9 GL999-E03 GL999-E04...
  • Page 10 GL999-E05...
  • Page 11 GL999-E06...
  • Page 12 GL999-E07...
  • Page 13 GL999-E08...

  • Page 14: Input Signals

    2.4 Input Signals 2.4.1 Video input • Type Analog R, G, B., Digital TMDS • Input Impedance 75 ohm +/- 2% • Polarity Positive • Amplitude 0 - 0.7 +/- 0.05 Vp • Display Color same as LCD panel 2.4.2 Sync input •...
  • Page 15 2.4.4 Support Timing Table Mode Resolution Pixel Clock Frequency Total Width Frequeny Total Width output output output 640x350(50Hz) 25.175M 31.469KHz 50.030Hz 640x350(60Hz) 25.175M 31.469KHz 59.941Hz IBMG 640x350(70Hz) 25.175M 31.469KHz 70.087Hz 720x350(50Hz) 28.322M 31.469KHz 50.030Hz 720x350(60Hz) 28.322M 31.469KHz 59.941Hz IBMT 720x350(70Hz) 28.322M 31.469KHz 70.087Hz...
  • Page 16 Mode Resolution Pixel Clock Frequency Total Width Frequeny Total Width output output output VESA 640x480(50Hz) 25.175M 31.469KHz 50.030Hz VESA 640x480(60Hz) 25.175M 31.469KHz 59.941Hz 640x480(66Hz) 31.330M 34.970KHz 66.600Hz 640x480(70Hz) 30.284M 36.052KHz 70.004Hz VESA 640x480(72Hz) 31.500M 37.861KHz 72.810Hz VESA 640x480(75Hz) 31.500M 37.500KHz 75.000Hz VESA 800x600(56Hz)
  • Page 17 2.4.5 Video input Connector Analog Video input Connector: 15pins mini D-Sub Table 2.4.5. Pin assignment for D-sub connector Separate Sync RED VIDEO GREEN VIDEO BLUE VIDEO GROUND GROUND RED GROUND GREEN GROUND BLUE GROUND PC5V (+5V DDC) CABLE DETECTION GROUND H.SYNC V.SYNC Color of plastic parts: Blue...

  • Page 18: Controls

    2.5 CONTROLS Front View 2.5.1 Control panel (monitor front panel) ON/OFF Button Push once to turn your LCD display ON and push again to turn it OFF. Power LED The power LED will turn to green under normal operation and orange when in standby mode.

  • Page 19: Osd

    2.6 OSD Brightness Contrast Sharpness Exit OSD Transparency Input select Phase Language Clock Recall Graphic/text OSD VP OSD HP Color Temperature Note: , please refer to the enclosed files for the icon graphs , the below graph is just for reference, all icon’s sequence must follow the above setting. GL999-E19...
  • Page 20 Description: • Brightness: Brightness adjustment, the range from 0 to 100. Default = 80 • Contrast: Contrast adjustment, the range from 0 to 100. Default = 80 • H. Position: Horizontal position adjustment. • V. Position: Vertical position adjustment. • Phase: Focus adjustment, the range from 0 to 100 steps.

  • Page 21: White Color Temperature

    2.7 White Color Temperature White color temperature is 4 preset as 9300, 6500 and User, Default value of user color should be user which is maximum setting for panel. Target of color setting Color Color Coordinate Tolerance Color Coordinate Tolerance Temp.

  • Page 22: Audio Technical Specification

    2.10 Audio Technical specification 2.10.1 General Description: Output power : 0.7W + 0.7W typ Total harmonic distortion : Less than 1 % (except speakers distortion) Input signal sensitivity : 0.5 Vrms for full output Input impedance : 47 Kohm +/- 5 % Frequency response range : 200Hz –...

  • Page 23: Appendix A: P.c.b.a Assembly

    APPENDIX A: P.C.B.A ASSEMBLY...
  • Page 24 401AAN.pdf 13.1.11 Material List by Parts-no Date: 09/19/03 Time: 10:08:15 R/N:ydr6068j - ================================================================================ =================================================== QUANTITY REQUIRED DWG.NO. 461AAN REV. 1A PART NO. DESCRIPTION SPECIFICATION ----- ------------- -------------------------------------- REMARKS - ---- ----------- ------------------------ ------------------------------ --- - -- --- --- --- ----- ----- ----- ----- ----- ----- # 461AAN30001 FIRMWARE CTRL/B VL-910 LGL999F AGN 1 451AAN30001 PCBA CTRL/B...
  • Page 25 6 CB047A6M300 ECE CAP(NP) 4.7U 50V M A P2.0 L4.5 5X11 - C95 7 CB100034000 ECE CAP 100U 16V M A P2.0 L4.5 5X11 - C101 C106 C118 C120 C820 8 CB10012M020 ELE CAP 1000U 10V M A P5 L4.5 10X12 - C84 9 CB10012M110 ELE CAP 1000U 10V M B P3.5 L9.5 ESR 8D...
  • Page 26 13.1.11 Material List by Parts-no Date: 09/19/03 Time: 10:09:12 R/N:ydr6068j - ================================================================================ =================================================== QUANTITY REQUIRED DWG.NO. 451AAN REV. 1A PART NO. DESCRIPTION SPECIFICATION ----- ------------- -------------------------------------- REMARKS - ---- ----------- ------------------------ ------------------------------ --- - -- --- --- --- ----- ----- ----- ----- ----- ----- # 431AAN30001 SMT CTRL/B VL-910 LGL999F 1 DA4L999V010 PCB...
  • Page 27 22 SD0130000T4 CHIP RES. 1/16W 0 +5% 0603 - FB1 L501 L502 L503 R102 R107 R115 23 SD0131000T9 CHIP RES. 1/16W 100 +-5% 0603 - R11 24 SD0131001T6 CHIP RES. 1/16W 1K +-5% 0603 - R112 R113 R120 25 SD0131002T3 CHIP RES. 1/16W 10K +-5% 0603 - R114 R122...
  • Page 28 13.1.11 Material List by Parts-no Date: 09/19/03 Time: 10:09:12 R/N:ydr6068j - ================================================================================ =================================================== QUANTITY REQUIRED DWG.NO. 451AAN REV. 1A PART NO. DESCRIPTION SPECIFICATION ----- ------------- -------------------------------------- REMARKS - ---- ----------- ------------------------ ------------------------------ --- - -- --- --- --- ----- ----- ----- ----- ----- ----- 33 SD0134701T8 CHIP RES.
  • Page 29 C821 46 SE051153Z00 S CER CAP 0.015U 25V Y5V Z 0603 - CZ1 47 SE092334K00 S CER CAP .33U 10V +-10% X7R 0805 - C91 48 SH122101M00 CHIP COIL 100uH +-20% AX98-50101 - L802 49 SM010006300 CHIP EMI SUPPRESSOR MURATA BLM21P300S (0805) - FB10 FB11 FB12...
  • Page 30 404AAN.pdf 13.1.11 Material List by Parts-no Date: 09/19/03 Time: 10:09:48 R/N:ydr6068j - ================================================================================ =================================================== QUANTITY REQUIRED DWG.NO. 454AAN REV. 1A PART NO. DESCRIPTION SPECIFICATION ----- ------------- -------------------------------------- REMARKS - ---- ----------- ------------------------ ------------------------------ --- - -- --- --- --- ----- ----- ----- ----- ----- ----- # 454AAN30001 PCBA KEY/B VK-910 LGL999F 1 BC40HZ6B2T7 ZENER DIODE...

  • Page 31: Appendix B: Display Unit Assembly

    APPENDIX B: DISPLAY UNIT ASSEMBLY...
  • Page 33 13.1.11.4 Material List by Location Date: 09/18/03 Time: 17:06:53 R/N:ydr6069j - ================================================================================ =================================================== QUANTITY REQUIRED DWG.NO. LGL999 REV. 1A PART NO. DESCRIPTION SPECIFICATION ----- ------------- -------------------------------------- 001 001 001 001 REMARKS - ---- ----------- ------------------------ ------------------------------ --- - -- --- --- --- ----- ----- ----- ----- ----- ----- # LGL999F0001 LGL999F AGN(E-19A) UR+TCO95 MBK24 19"FUJ W/SPK # LGL999F2001 LGL999F AGN-EU-BLACK...
  • Page 34 ------------- -------------------------------------- REMARKS - ---- ----------- ------------------------ ------------------------------ --- - -- --- --- --- ----- ----- ----- ----- ----- ----- # X66AQ330001 MEC PACKING AGN(E-19A) LGL999F 1 FJGL9918000 EPE RIGHT GL9918 - 201 2 FJGL9919000 EPE LEFT GL9919 - 202 End of Report End of Report...
  • Page 35 1 EJ4GL999000 RATING NP(E-19A) N-GL999-AGN UFGC - 001 2 FCTLP2S0116 HANDLE FOR CARTON - 002 3 HB4GL677000 CARTON C-GL677-AGN E SERIES - 003 4 HF6GL677000 QUICK GUIDE F-GL677-AGN E SERIES - 004 5 HF6GL677300 CD SHEET F-GL677-AGN FOR CD - 005...
  • Page 37 13.1.11.4 Material List by Location Date: 09/18/03 Time: 17:07:55 R/N:ydr6069j - ================================================================================ =================================================== QUANTITY REQUIRED DWG.NO. 582915 REV. 1A PART NO. DESCRIPTION SPECIFICATION ----- ------------- -------------------------------------- REMARKS - ---- ----------- ------------------------ ------------------------------ --- - -- --- --- --- ----- ----- ----- ----- ----- ----- # 58291530001 DIS UNIT AGN(E-19A) LGL999F TCO95 19"FUJ 1280X1024 1 AC6VF190010 LCD MODU...
  • Page 38 13.1.11.4 Material List by Location Date: 09/22/03 Time: 11:33:46 R/N:ydr6069j - ================================================================================ ==================================================== QUANTITY REQUIRED DWG.NO. X66AQ4 REV. 1A PART NO. DESCRIPTION SPECIFICATION ----- ------------- -------------------------------------- REMARKS - ---- ----------- ------------------------ ------------------------------ --- - -- --- --- --- ----- ----- ----- ----- ----- ----- # X66AQ430001 MEC PARTS AGN(E-19A) LGL999F TCO95 MBK24 1 ECGL9913000 CHASSIS...
  • Page 39 - 021 22 MAB10001413 SCREW TPB-3+6F-MC - 022 23 MAB20000200 SCREW TPP-3X10P-ZK - 023 24 MAB20055109 TAPING SCREW TPB-3+8 P-MC - 024 25 MAB70071400 TAPPING SCREW TPB-3+12C-MC - 025 End of Report...
