3. Printing does not resume after changing the print
head.
The print head is not inserted/fixed correctly.
Make sure the print head is inserted and fixed towards
the rear of the printer.
See Chapter 2 - "Ink Jet Print Head" for the correct print
head replacement procedure.
4. Poor print quality .
(a) Leggibility
Clean the print head, clicking on the appropriate button
in the Printer Care tab in the Printer Monitor.
Clean the electrical contacts on the print head and those
in the print head carriage.
Try printing on the other side of the paper.
Make sure you are using good quality paper.
(b) Character alignment
In Windows® environment, access the Printer Care tab
in the Printer Monitor and run the "ALIGN" function, to
correct possible bi-directional disalignment of the char-
acters (see Checking print accuracy in the Quick Start ).
Troubleshooting
5. Strange characters are printed
Check that the driver you have selected is
compatible with the emulation/application you are
using.
Check the interface cable quality and length (max.
recommended length : 2 meters)
Check that the character set you require is selected (the
currently selected parameters, including the character
set, are given in the monochrome print test - see the
previous section of this chapter).
With some applications (CorelDraw, Designer, etc.), you
may obtain strange print-outs (extra-large characters,
altered character spacings, incorrectly proportioned
graphics). This is due to difficulties in handling the
non-square resolution (600 x 300 dpi) used in
Presentation Print Quality. If this occurs, you should
select High Quality.
If you have an "ECP" computer, check its printer port is
Printer Port: LPTx. If necessary, change the port
setting in your system properties (see point 5 in
" Installation ").
If you cannot solve this problem, your technical support
service may request to run a hex-dump of a test piece to
check that the data transmission is operative. To run the
hex-dump, proceed as follows:
– Press in sequence and hold together On Line, Install
Cartridge and Form Feed, until the light indicators go
off, then release together. Then press in sequence
On Line, Form Feed, Install Cartridge.
5-9
