Print Area

The following tables contain the measurements of the
physical print area on the document and envelope sizes
handled by the printer. The printer can print a maximum of
67 lines on an A4 page with 6 lpi linespacing (the last line
may be printed with slightly defective linespacing).
Please note that:
The physical print area is the maximum print area
available on your document.
The recommended print area is generally always smaller
than the physical print area. Your application may also
add its own default margins to your page layout, thus
further reducing the print area.
Pre-printed documents MUST have at least a 5 mm
(0.2 in) margin before the first print position.
For best quality printing, a 12.7 mm (0.5 in) top margin
and 27 mm (1.06 in) bottom margin are recommended.
Use of documents that do not conform to the
specifications indicated will result in crooked or incorrect
insertion and feed-through, with a risk of jamming.
3-4
Single sheets
Page length 297 mm/
11.7 in
Page width 210 mm/
8.26 in
Maximum 203.2 mm/
length of print 8 in
line
Minimum left/ 3.4 mm/
right hand 0.134 in
margin
Top margin
Bottom margin
148.5 mm/ 279.4 mm/ 266.7 mm/
5.85 in 11 in 10.5 in
210 mm/ 215.9 mm/ 184.2 mm/
8.26 in 8.5 in 7.25 in
203.2 mm/ 203.2 mm/ 177.8 mm/
8 in 8 in
3.4 mm / 6.4 mm/ 3.1 mm/
0.134 in 0.25 in 0.125 in
3 mm / 0.12 in (minimum)
12.7 mm / 0.5 in (minimum)
7 in
Paper
