Installing the SuperScript 150C color
printer driver
The installation procedure will vary, depending on the
Windows® environment installed on your PC.
Windows® 3.1/3.11
1. Start Microsoft Windows®.
(If it is already running, make sure that all applications
are closed before starting to install the driver.)
2. Insert the driver diskette in drive A (or B) of your PC.
3. From the File menu of the Program Manager, select the
option "Run...".
4. Type A:(or B:)\SETUP and press ENTER.
The installation process starts.
5. Follow the instructions given in the sequence of windows
displayed on your PC screen, until the driver is installed.
6. A group window with the driver name will be created
automatically. It allows immediate access to the Spool
Manager, the Printer Monitor, the Help and information
files whenever these are required.
You can also install the printer driver through the "Add
Printer" feature in the Control Panel in Program
Manager/Main, proceeding as follows. The group
described in point 6 above will still be created automatically.
10
1. Insert the diskette in drive A (usually) of your PC.
2. Activate Microsoft Windows® environment (If it is
already running, make sure that all Windows application
tasks are closed before starting to install the driver.)
3. Activate the Control Panel in the Main window, clicking
twice with your mouse indicator on the corresponding
icon.
4. Select the Printers icon, in the same way.
5. If the Installed Printers box is empty, click on Install..
6. If the Installed Printers box already contains one or
more driver names, click on Add>> , select Install
Unlisted or Updated Printer in the List of Printers and
then click on Install... .
7. Check that the Install Driver window already indicates
the drive (usually A) in which you have inserted the
driver diskette, otherwise, click on the drive name and
change it, using your PC keyboard; click on OK.
8. The Add Unlisted or Updated Printer window contains
the list of drivers present on the diskette. Select the
driver with your printer name and click on OK.
9. Your driver is now installed and your printer name
appears in the List of Printers.
10. With your printer name highlighted, click on the Set as
Default Printer button, so that your printer will be active
in all your Windows® applications.
11. Check your printer connection by clicking on the
Connect.. button.
