AdderLink Digital iPEPS features

The AdderLink Digital iPEPS unit uses the following connections to provide
secure remote access to a host computer.
USB link for keyboard and mouse
Use this port to link the Digital iPEPS to
a USB port on the host computer. This
will provide USB keyboard and mouse
connections.
USB link for the Adder Virtual Media feature
Optionally use this port to link the Digital iPEPS to
a USB port on the host computer. This will provide
a USB connection specifically for the Adder Virtual
Media feature.
Video input
DVI/D digital video input from the
host computer.
RS232 serial input
Optionally use the
supplied power control
cable to link this port
with the RS232 port of
a power switch.
IP network port
This Ethernet port provides the connection
to the network. The port is intelligent
and can automatically sense whether it is
attached to a 10Mb or 100Mb network
and whether a cross-over or straight cable
is in use. The green and yellow indicators
provide useful status information.
Audio input
Optionally use the
supplied 3.5mm jack
cable to link this port
with the audio output
of the host computer.
N O
1
2
Power input Configuration switches
SW1
Connect the supplied is used to determine
power adapter here. how Digital iPEPS derives
its power. SW2 is used
to reset the Digital iPEPS
back to its factory defaults.
SW2 is also used during
firmware upgrades.
4
