Auto Calibrate; Re-Synchronise Mouse; Access Mode - Shared/Private; Power Switching - ADDER AdderLink Digital iPEPS User Manual

Auto calibrate

Auto calibrate will calibrate the mouse only if relative mouse mode is selected.
This detects the mouse motion and will report back that the mouse has been
calibrated correctly depending upon the operating system.
See the notes on Advanced mouse configuration
Once this has been done, providing you use the 'Hosts' button to switch
between host computers, the video settings for each machine will be re-used.

Re-synchronise mouse

If you find that your local mouse pointer and that of the host are not correctly
synchronised, use this feature to re-align their movements. This operation is also
selectable from the Controls menu.
To re-synchronise the mouse
1 Use the Hosts button to select the required computer.
2 Click the button and then click OK in the subsequent pop-up message.
Note: If you find that this doesn't work, you may need to perform a mouse
calibration again.

Access mode - shared/private

Up to four users can be simultaneously logged-in and all will view the same
host. If you need to perform a sensitive task that should not be viewed by other
users, you can change the access mode to Private. This action prevents other
users connecting at the same time.
for more details.
To change the access mode

Power switching

When configured (and where you have access rights) this option allows you to
control the mains power input to the currently selected host computer.
Note: This option is generally used to power cycle remote systems that have
failed to respond. Before switching a system off, ensure that all attempts have
first been made to power it down through normal means.
To switch a system on or off
1 Click one of the arrow buttons adjacent to the
Shared/Private indicator.
1 Use the Hosts button to select the required
computer.
2 Click the Power button and then select the Switch
on or Switch off option, as appropriate.
15
