- Page 1 Adaptec RAID Controller Command Line Utility User’s Guide...
- Page 2 Sierra, Inc. Trademarks PMC, PMC-Sierra, and Adaptec are registered trademarks of PMC-Sierra, Inc. “Adaptec by PMC” is a trademark of PMC-Sierra, Inc. Other product and company names mentioned herein may be trademarks of their respective owners. For a complete list of PMC-Sierra trademarks, see www.pmc-sierra.com/legal.
- Page 3 Adaptec by PMC Product Support If you have questions about installing or using your Adaptec by PMC product, check this document first—you will find answers to most of your questions. If you need further assistance, use the support options listed below. To expedite your service, have your computer in front of you.
- Page 4 ● Software License Agreement PLEASE READ CAREFULLY: THE USE OF THIS SOFTWARE IS SUBJECT TO THE SOFTWARE LICENSE TERMS OF PMC-SIERRA, INC. AND OTHER LICENSORS WHOSE SOFTWARE MAY BE BUNDLED WITH THIS PRODUCT. BY YOUR USE OF THE SOFTWARE INCLUDED WITH THIS PRODUCT YOU AGREE TO THE LICENSE TERMS REQUIRED BY THE LICENSOR OF THAT SOFTWARE, AS SET FORTH DURING THE INSTALLATION PROCESS.
- Page 5 ● 12. General. You acknowledge that you have read this Agreement, understand it, and that by using the Software you agree to be bound by its terms and conditions. You further agree that it is the complete and exclusive statement of the agreement between PMC-Sierra and you, and supersedes any proposal or prior agreement, oral or written, and any other communication between PMC-Sierra and you relating to the subject matter of this Agreement.
-
Page 6: Table Of Contents
Contents Getting Started with the Command Line Utility Installing the Command Line Utility..............9 Installing on Windows.................. 9 Installing on Red Hat, SuSE, or Fedora Linux ..........9 Installing on Debian or Ubuntu Linux............9 Installing on OpenServer and UnixWare ..........10 Installing on Solaris .................. - Page 7 Contents ● arcconf playconfig..................22 arcconf rescan ..................... 23 arcconf resetstatisticscounters..............23 arcconf romupdate ..................23 arcconf saveconfig..................24 arcconf savesupportarchive................ 24 arcconf setalarm..................25 arcconf setcache ..................25 arcconf setconfig ..................26 arcconf setmaxiqcache................26 arcconf setname ..................27 arcconf setncq .....................
- Page 8 Getting Started with the Command Line Utility In this chapter... Installing the Command Line Utility ..................9 Starting the Command Line Utility ..................12 ™ ® This chapter explains how your Adaptec by PMC RAID controllers support the use of the ARCCONF command line utility.
-
Page 9: Getting Started With The Command Line Utility
Chapter 1: Getting Started with the Command Line Utility ● Installing the Command Line Utility The ARCCONF command line utility is provided on the Adaptec RAID Controller Installation DVD. The utility is automatically installed in the same directory as Adaptec Storage Manager and must remain there. -
Page 10: Installing On Openserver And Unixware
Chapter 1: Getting Started with the Command Line Utility ● Change to the Debian manager directory: cd /mnt/cdrom/ASMCD/debian_x86_64/manager Install the .deb package: dpkg -i storman_6.50-15653_amd64.deb (for 64-bit systems) Unmount the RAID Controller Installation DVD: umount /mnt/cdrom Installing on OpenServer and UnixWare... -
Page 11: Installing On Freebsd
ESX Server 3.5: cd /mnt/cdrom/ASMCD/linux/manager ESX Server 4.x: cd /mnt/cdrom/ASMCD/linux_64/manager Extract the Linux Adaptec Storage Manager RPM package and install it: rpm --install --nodeps ./StorMan*.rpm Note: Ignore the message "Application can be started by typing /usr/StorMan/ StorMan.sh". VMware does not support the Adaptec Storage Manager GUI. -
Page 12: Starting The Command Line Utility
Chapter 1: Getting Started with the Command Line Utility ● Starting the Command Line Utility To start , enter one of the following commands: ARCCONF Windows— ● <install_dir>\arcconf.exe Linux— ● /usr/<install_dir>/arcconf UnixWare/OpenServer— ● /opt/RaidMan/arcconf Solaris— ● /usr/StorMan/arcconf FreeBSD— ● /<install_dir>/arcconf VMware—... - Page 13 In this chapter... ARCCONF Commands ......................14 This chapter explains how to use the command line utility interactively or in batch mode. With interactive mode, enter commands at the prompt. In batch mode, create scripts and run the script in the appropriate shell. For example:...
-
Page 14: Using The Command Line Utility
Chapter 2: Using the Command Line Utility ● ARCCONF Commands Perform the following functions from the command line: ARCCONF COMMANDS atapassword getsmartstats resetstatisticscounters setncq copyback getstatus romupdate setperform create getversion saveconfig setpower datascrub identify savesupportarchive setpriority delete imageupdate setalarm setstate... -
Page 15: Arcconf Create
Chapter 2: Using the Command Line Utility ● Example ARCCONF COPYBACK 1 ON arcconf create Creates a new logical drive or JBOD. You must provide the channel and device ID of the physical devices. On redundant logical drives, ARCCONF performs autosynchronization. -
Page 16: Arcconf Datascrub
Chapter 2: Using the Command Line Utility ● RAID# indicates the RAID level for the new logical drive. 0, 1, 1E, 10, 5, 5EE, 50, 6, 60, and volume are supported. Channel# Drive# lists the space-delimited channel number and device number pairs for each device to add to the logical drive. -
Page 17: Arcconf Driverupdate
Chapter 2: Using the Command Line Utility ● LogicalDrive|JBOD ALL deletes all logical drives or JBODs. Noprompt is an optional parameter that suppresses alert messages. Examples ARCCONF DELETE 1 LOGICALDRIVE 1 2 3 ARCCONF DELETE 1 JBOD ALL arcconf driverupdate Updates Windows device drivers. -
Page 18: Arcconf Getlogs
Chapter 2: Using the Command Line Utility ● Physical device state ● Number of Solid State Disks (SSDs) assigned to MaxIQ pool, maximum number of SSDs ● that can be assigned to MaxIQ pool Enclosure information: fan, power supply, and temperature status ●... -
Page 19: Arcconf Getsmartstats
ARCCONF GETLOGS 1 STATS Tabular arcconf getsmartstats Displays SMART statistics for the hard drives and Solid State Drives (SSDs) on a controller. Note: For more information about SMART statistics, see the Adaptec Storage Manager User’s Guide. Syntax ARCCONF GETSMARTSTATS <Controller#> [Tabular] Parameters Controller# is the controller number. -
Page 20: Arcconf Identify
Chapter 2: Using the Command Line Utility ● Syntax ARCCONF GETVERSION (use this for information on all controllers) ARCCONF GETVERSION <Controller#> (use this for information on a specific controller) Parameters Controller# is the controller number Example ARCCONF GETVERSION arcconf identify Identifies a physical or logical device by blinking its LEDs. -
Page 21: Arcconf Key
Chapter 2: Using the Command Line Utility ● 7-(SAS) Download microcode with offsets, save, and activate ● Noprompt is an optional parameter that suppresses alert messages. Example ARCCONF IMAGEUPDATE 1 DEVICE 0 83 16384 ados.lod 3 arcconf key Loads a feature key onto an Adaptec controller. -
Page 22: Arcconf Playconfig
Chapter 2: Using the Command Line Utility ● Channel# is the channel number for the device. Drive# is the device_ID (device number) for the device. Noprompt is an optional parameter that overrides the user prompt. Examples ARCCONF MODIFY 1 FROM 2 TO 2048 0 0 123 0 124 0 117... -
Page 23: Arcconf Rescan
Chapter 2: Using the Command Line Utility ● arcconf rescan Enables the controller to check for the removal of any disk drives in the ready state and to check for the connection of any new disk drives to the controller. The command returns when the rescan is complete. -
Page 24: Arcconf Saveconfig
ARCCONF SAVECONFIG server1_config.xml C:\LOGS\SERVER1.LOG arcconf savesupportarchive Saves configuration and status information to help Adaptec Customer Support diagnose a problem with your system. Saved information includes (but is not limited to) device logs, drive logs, event logs, error logs, controller logs, and SSD SMART statistics. (For more information... -
Page 25: Arcconf Setalarm
Chapter 2: Using the Command Line Utility ● Example ARCCONF SAVESUPPORTARCHIVE arcconf setalarm Sets the state of the controller audible alarm, if present. Syntax ARCCONF SETALARM <Controller#> <on|off|silence|test> Parameters Controller# is the controller number On enables the alarm Off disables the alarm... -
Page 26: Arcconf Setconfig
Chapter 2: Using the Command Line Utility ● arcconf setconfig Resets the controller's configuration. Logical drives are deleted, hard disks are reset to the READY state, and any controller settings are reset to default values. Syntax ARCCONF SETCONFIG <Controller#> DEFAULT [noprompt]... -
Page 27: Arcconf Setname
Chapter 2: Using the Command Line Utility ● arcconf setname Renames a logical drive. Syntax ARCCONF SETNAME <Controller#> LOGICALDRIVE <LogicalDrive#> <New Name> Parameters Controller# is the controller number LogicalDrive# is the number of the logical drive to be renamed New Name is the new name of the logical drive... -
Page 28: Arcconf Setpriority
Chapter 2: Using the Command Line Utility ● Parameters Controller# is the controller number. Stayawake sets the stayawake period for the disk drives on the controller. During the stayawake period, the disk drives always operate at their peak spin rate. -
Page 29: Arcconf Setstate
Chapter 2: Using the Command Line Utility ● Task ID is the number of the task to be changed. Use arcconf getstatus to obtain the task ID. Omit this parameter to set the controller’s global background task priority; that is, the execution priority for all tasks on the controller. -
Page 30: Arcconf Setstatsdatacollection
Chapter 2: Using the Command Line Utility ● arcconf setstatsdatacollection Enables or disables statistics collection for a controller. To display the statistics, use the arcconf getlogs command (see page 18). Syntax ARCCONF SETSTATSDATACOLLECTION <Controller#> Enable|Disable Parameters Controller# is the controller number. - Page 31 PMC-Sierra, Inc. 1380 Bordeaux Drive Sunnyvale, CA 94089 USA © Copyright PMC-Sierra, Inc. 2011 All rights reserved. Adaptec and the Adaptec by PMC logo are trademarks of PMC-Sierra, Inc. Part Number: CDP-00262-01-A, Rev A JPB 03/11...
