Intergraph InterServe 600 Series System Reference Manual page 90

82
4. Loosen the screw to allow the pivoting ISA board guide to swing toward the system fans. Refer to
the following figure.
Screw
ISA Board
Guide
5. Install the option board into the first available slot from the system board. Press firmly to ensure
the board seats completely in the slot.
6. Slide the pivoting board bracket over the edge of the ISA board; then tighten the screws.
7. Secure the ISA board to the chassis by installing the I/O lock bracket, which installs in only one
orientation. Mount the bracket to the chassis using the screw removed previously.
8. Close the base unit.
9. Restart the system. If you installed an ISA board, the installation is complete. If you installed a
PnP board, notice when the following message displays.
Hit DEL if you want to run SETUP
10. Press
DELETE
11. When the main menu displays, select the Advanced Setup icon.
12. Click on the Boot to PnP Operating System parameter and select Enable in the Options menu.
Press
ENTER
13. Exit AMIBIOS Setup and restart the system.
to run AMIBIOS Setup.
.
