MCBL054A -- MESAN150 J5 to CINF026 CHN 2
Pin Signal
1-16 Ground
17 Term Power
18 Term Power
19 No Connect
20-34 Ground
35 SCSI Data Bit 12
36 SCSI Data Bit 13
37 SCSI Data Bit 14
38 SCSI Data Bit 15
39 SCSI Data Parity 1
40 SCSI Data Bit 0
41 SCSI Data Bit 1
42 SCSI Data Bit 2
43 SCSI Data Bit 3
44 SCSI Data Bit 4
45 SCSI Data Bit 5
46 SCSI Data Bit 6
47 SCSI Data Bit 7
48 SCSI Data Parity 0
49 SWAP (Ground)
Pin Signal
50 Shell OK (Ground)
51 Term Power
52 Term Power
53 No Connect
54 Fault Clock (Ground)
55 Attention
56 Fault Data
57 Busy
58 Acknowledge
59 Reset
60 Message
61 Select
62 Carrier Detect
63 Request
64 I/O
65 SCSI Data Bit 8
66 SCSI Data Bit 9
67 SCSI Data Bit 10
68 SCSI Data Bit 11
