Expansion Slots
The motherboard contains two expansion slots: one PCI Express x16 slot and one
Mini PCI Express slot.
MINI_PCIE1
PCIEX16
Mini PCI Express Slot-MINI_PCIE1
There is one Mini PCIe slot, reserved for the WiFi Module.
PCI Express x16 Slot-PCIEX16
There is one PCIe x16 slot reserved for graphics card. It is fully compliant with PCI
Express 2.0 specification.
