Zotac A75ITX series User Manual page 8

Figure 2: Backpanel connectors
1
2
1. PS2 Keyboard/Mouse Port
2. USB 3.0 Ports
3. Clear CMOS Button
4. HDMI Port
5. Optical SPDIF Output
6. Port 2-Channel
Blue Line-In
Green Line-Out
Pink Mic In
Black --
Orange --
7. LAN port LED indicators
Speed LED Activity LED
8. DVI-I Port (single-link DVI-I)
9
8
3 4
4-Channel
Line-In
Front Speaker Out
Mic In
--
Rear Speaker Out
Speed LED
Status
Off
Green
Orange
7
2
6-Channel
Line-In
Front Speaker Out
Mic In
Center/Subwoofer
Rear Speaker Out
Description
Speed: 10 Mbps
Speed: 100 Mbps
Speed: 1000 Mbps
Rear Panel
6
5
8-Channel
Side Speaker Out
Front Speaker Out
Mic In
Center/Subwoofer
Rear Speaker Out
Activity LED
Status Descritption
Off No link
Orange Linked
Blinking Data activity
7
