iMediaChassis/3 Specifications

Input Specifications
AC 100 to 240V AC, 50/60Hz, 0.75A
DC 35V DC to 75V DC Max, 1.6A
Operating Temperature
AC 0° C to 50° C (32° F to 122° F)
DC -40° C to 50° C (-67° F to 122° F)
Storage Temperature
AC -40° C to 85° C (-40° F to 185° F)
DC -55° C to 125° C (-40° F to 212° F)
Humidity: 5 to 95% (non-condensing); 0 to 10,000 ft. altitude
Shipping Weight: 5 lbs (2.3 kg)
Dimensions: H=1.73" W=7.50" D=8.74" (4.4 x 19.0 x 22.0 cm)

Hardware Feature Matrix

Power Supply
Versions
Type
End user replaceable
LEDs
Redundant upgrade on single slot chassis
*Trap can be set for exceeding a temperature value
iMediaChassis/3
AC, 2AC, DC, 2DC*, ACDC
Fixed
No
Yes
No
23
