IMC Networks iMediaChassis/6 Operation Manual

Hide thumbs Also See for iMediaChassis/6:
Table of Contents

Advertisement

Quick Links

Download this manual
iMediaChassis/6
Operation Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the iMediaChassis/6 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for IMC Networks iMediaChassis/6

Summary of Contents for IMC Networks iMediaChassis/6

  • Page 1 Operation Manual...

  • Page 2: Fcc Radio Frequency Interference Statement

    At its option, IMC Networks will repair or replace at no charge the product which proves to be defective within such warranty period. This limited warranty shall not apply if the IMC Networks product has been damaged by unreasonable use, accident, negligence, service or modification by anyone other than an authorized IMC Networks Service Technician or by any other causes unrelated to defective materials or workmanship.

  • Page 3: Table Of Contents

    About the iMediaChassis/6 ..................1 Installing the iMediaChassis/6.................1 Installing Modules ....................3 SNMP Management Module LEDs .................3 Connecting Managed Chassis/Modules or Modules with Built-in Management ..4 Configuring the iMediaChassis/6 with an SNMP-Management Card......4 Serial Port Configuration ..................7 IMC Networks Technical Support.................15 Safety Certifications....................19...
  • Page 4 Notes...

  • Page 5: About The Imediachassis/6

    Manage an iMediaChassis/6 by installing a Management Module. Without the Module, the chassis remains unmanaged. Before installing the application modules into an iMediaChassis/6 install the chassis first. When installing the chassis, be sure to observe the following precautions to prevent electrical or mechanical damage: •...
  • Page 6 AC power supplies (rear view) iMediaChassis/6 with dual DC power supplies (rear view)

  • Page 7: Installing Modules

    Installing the SNMP Management Modules In order to manage an iMediaChassis/6, a SNMP Management Module must be installed. SNMP Management Modules install in the first slot, on the far left of the chassis. This slot is ONLY for the management module; do not install Application Modules such as media conversion and mode conversion modules in this slot.

  • Page 8: Connecting Managed Chassis/Modules Or Modules With Built-In Management

    Connecting Modules An iMediaChassis/6 with an installed management module connects to the LAN via an external 10/100 twisted pair connection. Connect the chassis to the network by plugging one end of a CAT-5 twisted pair cable into the port labeled "MGMT" on the management card, or the management-enabled application card.
  • Page 9 retain configuration settings. Make sure the SNMP Write Lock switch is set to the LOCKED position. Save the PROM file periodically in case there is a need to replace the SNMP management module. If the management module is removed with the SNMP Write Lock switch set to NORMAL, all settings for the modules revert to those established by hardware switches.
  • Page 10 Telnet session at the same time. Dynamic Host Configuration Protocol (DHCP) A DHCP client in the iMediaChassis/6 is disabled by default. If a DHCP server is present on the network and DHCP is enabled, the DHCP client will initiate a dialogue with the server during the boot up sequence.

  • Page 11: Serial Port Configuration

    Serial Port Configuration The SNMP management modules used with iMediaChassis/6 features a serial port that includes an IBM-compatible DB-9 serial connector. To connect an iMediaChassis/6...

  • Page 12: Assigning Ip Information

    • Subnet Mask (mask to define IP subnet agent is connected to) • Default Gateway (default router for IP traffic outside subnet) Command List • I= Enter New Saved Parameter Values • P=Change Password • T=New Trap Destination • K=Remove ALL Trap Destinations •...

  • Page 13: Deleting Community Strings

    If the password(s) are lost, neither the end user nor IMC Networks can retrieve it. Please refer to the iConfig or HUBCTRL32 HELP files, depending on whether the product is current or legacy.
  • Page 14 Device-Specific Options—Downloading Files The iMediaChassis/6 allows firmware to be downloaded from a central server via TFTP protocol. Initiate this download via serial configuration or Telnet session. Make sure the IP Address and the name of the file are correct in the Current Values section of the Main Configuration screen.

  • Page 15: Downloading Files

    Downloading Files The iMediaChassis/6 accepts firmware downloads from a central server by using TFTP protocol. Use the serial configuration or Telnet session to perform this download. Ensure the IP address and the name of the files are correct in the Current Values section of the Main Configuration screen.
  • Page 16 (a.k.a. MIBs) into the application. The SNMP agent uses the following Enterprise- specific MIB file and standard MIBs, which can be found in the MIB directory on the CD included with the iMediaChassis/6: MCIMC.MIB Enterprise-specific information for the agent. For example, configuration information, port type information, link status, etc.
  • Page 17 Power Supplies, Alarms and Fans The iMediaChassis/6 ships with one or two AC or DC power supplies, or one of each, depending on the model. DC Power Supply Wiring Instructions The following shows wiring configurations for 48 VDC power supplies for the iMediaChassis/6.
  • Page 18 Alarm Reset Button When one power supply on the iMediaChassis/6 malfunctions, an alarm will sound to indicate the loss of one power supply. A red Alarm Reset button, located next to the power connector on the right side of the power supply, stops this alarm. Pressing this button stops the alarm.
  • Page 19 Notes...
  • Page 20 Notes...
  • Page 21 Notes...

  • Page 22: Imc Networks Technical Support

    IMC Networks Technical Support Tel: (949) 465-3000 or (800) 624-1070 (in the U.S. and Canada); +32-16-550880 (Europe) Fax: (949) 465-3020 E-Mail: techsupport@imcnetworks.com Web: www.imcnetworks.com Specifications Physical Specifications Dimensions: 1.75” x 17.35” x 10.65” (4.45cm x 44.07cm x 27.05cm) Environmental Operating Temperature: 32° - 122° F (0° - 50° C) Storage Temperature: 0°...

  • Page 23: Safety Certifications

    (73/23/EEC). Certified to Safety of Information Technology Equipment, Including Electrical Business Equipment. For further details, contact IMC Networks. European Directive 2002/96/EC (WEEE) requires that any equipment that bears this symbol on product or packaging must not be disposed of with unsorted municipal waste.
  • Page 24 © 2007 IMC Networks. All rights reserved. The information in this document is subject to change without notice. IMC Networks assumes no responsibility for any errors that may appear in this document. IE-MediaChassis/2 is a trademark of IMC Networks. Other brands or product names may be trademarks and are the property of their respective companies.
