Unmanaged Modules

Before installing, configure the iMcV-10G-Converter modules for desired features.
The DIP Switch settings enable the end user to select the speed/protocol, loopback
modes and Loss Carry Forward (LCF). The table below indicates the available features
and settings for the iMcV-10G-Converter modules.
Switch
1 "ON" to Enable LOS from XFP1 to XFP2
2 "ON" to Enable LOS from XFP2 to XFP1
5
OFF OFF
OFF ON
OFF OFF
OFF ON
5,4,3
ON OFF
ON OFF
ON ON
ON ON
6 "ON" to enable FAULT on DDMI alarm
7 Enable Loopback XFP1
8 Enable Loopback XFP2
Function
4 3 Combination of settings
OFF Use Internal clock
OFF OC-192 SONET/SDH (9.95 Gb/S)
ON 10G Ethernet (10.32 Gb/S)
ON 10G Fibre Channel (10.52 Gb/S)
OFF ITU G-709 OUT-2 (10.70)
ON 10G Ethernet G.702 (11.09Gb/S)
OFF N.A. (default 0,0,0)
ON
5
Default
OFF
OFF
OFF/OFF/
OFF
(Ethernet)
OFF
OFF
OFF
