OPERATING HEATER
Continued
n
MANUAL LIGHTING
PROCEDURE
1. Remove lower front panel (see
Figure 7 page 7).
2. Follow steps through 5 under
Lighting Instructions on page12.
3. With control knob
strike match. Hold match to pilot
until pilot lights.
4. Keep control knob pressed in for
30 seconds after lighting pilot. After
30 seconds, release control knob.
Follow step 8 under Lighting
Instuctions on page 12.
5. Replace lower front panel.
nINSPECTING BURNERn
Check pilot flame pattern and
burner flame pattern often.
PILOT FLAME PATTERN
Figure 20 shows a correct pilot
flame pattern. Figure 21 shows an
incorrect pilot flame pattern. The
incorrect pilot flame is not touching
thermocouple. This will cause the
thermocouple to cool. When the
thermocouple cools, the heater will
shut down. If pilot flame pattern is
incorrect, as shown in Figure 21.
l turn heater off (see To Turn
Gas to Appliance on page 11
for non-thermostat models or
page 12 for thermostat models.)
l see Troubleshooting. pages 14
through 16.
Figure 20 - Correct Pilot Flame
Pattern
Figure 21 - Incorrect Pilot Flame
Pattern
BURNER FLAME PATTERN
Figure 22 shows a correct burner
n
flame pattern. Figure 23 shows an
incorrect burner flame pattern. If
pilot flame pattern is incorrect, as
shown in Figure 23.
WARNING: If yellow tipping
occurs, your heater could
increased
pressed in,
monoxide. If burner
shows yellow tipping, follow instruc-
tions at
Notice: Do not mistake orange
flames with yellow tipping. Dirt or
other fine particles enter the heater
a n d b u r n
patches of orange flame.
l turn heater off (see To Turn Off
Gas to Appliance pages10 & 11
for non-thermostat models and
page 12 for thermostat models)
l see Troubleshooting. pages 14
through 16
Figure 22 - Correct Burner Flame
Pattern
Off
Figure 23 - Incorrect Burner
Flame Pattern
CLEANING AND
MAINTENANCE
WARNING: Turn off heater
and let cool before servicing.
CAUTION: You must keep con-
trol areas, burner, and circulating
air passageways of heater clean.
Inspect these areas of heater
before each use. Have heater
inspected yearly by a qualified
service person. Heater may need
more frequent cleaning due to
excessive
bedding material, pet hair, etc.
produce
levels of carbon
flame pattern
bottom of this page.
c a u s i n g b r i e f
lint from carpeting,
1 3
ODS/PILOT AND BURNER
l Use a vacuum cleaner, pres-
surized air or a small, soft
bristled brush to clean.
CLEANING BURNER
PILOT AIR INLET HOLE
We recommend that you clean the
unit every 2,500 hours of operation or
every three months. We also
recommend that you keep the burner
tube and pilot assembly clean and free
of dust and dirt. To clean these parts
we recommend using compressed
air no greater than 30 PSl. Your local
computer store, hardware store, or
home center may carry compressed
air in a can. You can use a vacuum
cleaner in the blow position. If using
compressed air in a can, please follow
the directions on the can. If you don't
follow directions on the can, you could
damage the pilot assembly.
1. Shut off the unit, including the
pilot. Allow the unit to cool for
at least thirty minutes.
2. Inspect burner and pilot for dust
and dirt.
3. Blow air through the ports/slots
and holes in the burner.
Also clean the pilot assembly. A
yellow tip on the pilot flame
cates dust and dirt in the pilot
assembly. There is a small pilot air
inlet hole about two inches from
where the pilot flame comes out of
the pilot assembly (see Figure 24).
With the unit off , lightly blow air through
the air inlet hole. You may blow through
a drinking straw if compressed air is
not available.
Figure 24 - Pilot Inlet Air Hole
CABINET
Air Passageways
Use a vacuum
l
pressurized air to clean.
Exterior
l Use a soft cloth dampened with
a mild soap and water mixture.
Wipe the cabinet to remove dust.
indi-
cleaner or
