Framing and Clearances

A. Selecting Appliance Location
When selecting a location for the appliance it is important to
consider the required clearances to walls (see Figure 5.1).
WARNING! Risk of Fire or Burns! Provide adequate
clearance around air openings and for service access.
Due to high temperatures, the appliance should be locat-
ed out of traffi c and away from furniture and draperies.
A
L
F
A
J
J
M
Models A
in. 42
QV32B-A
mm 1066
in. 45-1/2
QV36B-A
mm 1155 1067 1635
Figure 5.1 Appliance Locations
C
K
B C D
37 59-1/2
See Section
940 1511
D for Alcove
42 64-3/8
Installation
Quadra-Fire • QV32B-A, QV36B-A • 2014-900 Rev. U • 1/12
NOTICE: Illustrations refl ect typical installations and are
FOR DESIGN PURPOSES ONLY. Illustrations/diagrams
are not drawn to scale. Actual installation may vary due to
individual design preference.
