Congratulations - Quadra-Fire QV32B-A Owner's Manual

Read this manual before installing or operating this appliance.
A. Congratulations
Congratulations on selecting a Quadra-Fire gas fi replace, an
elegant and clean alternative to wood burning fi replaces. The
Quadra-Fire gas fi replace you have selected is designed to
provide the utmost in safety, reliability, and effi ciency.
As the owner of a new fi replace, you'll want to read and
carefully follow all of the instructions contained in this
owner's manual. Pay special attention to all cautions and
warnings.
Homeowner Reference Information
Model Name: ___________________________________________ Date purchased/installed: __________________
Serial Number: __________________________________________ Location on fi replace: _____________________
Dealership purchased from: _______________________________ Dealer Phone: __________________________
Notes: _______________________________________________________________________________________
_____________________________________________________________________________________________
Listing Label Information/Location
Type of Gas
Gas and Electric
Information
2
Please retain this owner's manual for future reference.
The model information regarding your specifi c fi replace can be found on
the rating plate usually located in the control area of the fi replace.
R .
Quadra-Fire, a brand of Hearth & Home Technologies, Inc.
7571 215th Street West, Lakeville, MN 55044
Not for use with solid fuel.
(Ne doit pas entre utilise avec un combustible solide).
Ty pe of Gas (Sorte De Gaz) : This appliance must be installed in a ccordance with local codes, if any; if not, follow ANSI Z 223.1
in th e US A or CAN/CG A B149 installation codes. (Installer l' appa re il selon les codes ou regl emen ts
N A TURA L GA S
lo caux ou , en l'absence de te ls reglements, selon les codes d'in stallation CAN/CGA-B149.)
Minimum Permissible Gas Supply for Purpos es of Input Adjustment .
Approved Minimum (De Gaz) Acceptabl e
Maximum Pressure (Pression)
Maximum Manifold Pressure (Pression)
Minimum Manifold Pressure (Pression)
To tal Electrical Requirements: 000V ac, 00Hz., less than 00 Ampere s
IN CANADA
AL TI TUDE : 0-0000 FT . 0000-0000FT .
MAX. INPU T BTUH: 00,000 00,000
MIN. INPU T BTUH: 00,000 00,000
ORIFICE SIZE: #XXXXX #XXXXX
Quadra-Fire • QV32B-A, QV36B-A • 2014-900 Rev. U • 1/12
This owner's manual should be retained for future
reference. We suggest that you keep it with your other
important documents and product manuals.
The information contained in this owner's manual, unless
noted otherwise, applies to all models and gas control
systems.
Your new Quadra-Fire gas fi replace will give you years of
durable use and trouble-free enjoyment. Welcome to the
Quadra-Fire family of fi replace products!
We recommend that you record the following pertinent
information about your fi replace.
ANSI Z21X X-XXXX · CS A 2.XX-MXX · UL307B
0. 0 in w. c. (Po. Col. d'eau)
0. 0 in w. c. (Po. Col. d'eau)
0. 0 in w. c. (Po. Col. d'eau)
0. 0 in w. c. (Po. Col. d'eau)
Mode l:
XXXXXXXX
(Modele):
Serial
X XXXXXXX
(Serie):
Model Number
MADE IN US A
Serial Number
