Quadra-Fire QV32B-A Owner's Manual page 31

Rear Vent - Horizontal Termination
No Elbows
Note: Use DVP Series
components only.
Figure 7.12
Note: Use DVP Series
components only.
Figure 7.13
Rear Vent - Horizontal Termination
Venting with 2 elbows
H MAX.
1
1-1/2 ft. 457 mm Back to back elbows
3 ft. 914 mm
5 ft. 1.5 m
7 ft. 2.1 m
H
2
Quadra-Fire • QV32B-A, QV36B-A • 2014-900 Rev. U • 1/12
H = 24 in. (711 mm) Maximum
1
H
1
V MIN. H MAX.
1 2
1 ft. 305 mm 2-1/2 ft. 762 mm
1 ft. 305 mm 3 ft. 914 mm
3 ft. 914 mm 5 ft.
5 ft. 1.5 m 7 ft.
H MAX. = 7 ft. (2.1 m)
1
H + H MAX. = 14 ft. (4.3 m)
1 2
V + H + H MAX. = 40 ft. (12.2 m)
1 1 2
V
1
H + H MAX.
1 2
6 ft. 1.8 m
1.5 m 10 ft. 3.0 m
2.1 m 14 ft. 4.3 m
H
1
31
