Under n ocircumstances arethesurface burner
assemblies t obetakenapart f orcleaning. Thesurface
burner assembly c anberemoved t ocleantheburner box
area.
The two surface burner assemblies are secured in place
during transportation with screws. Once the range is
installed, these screws may be removed to allow quick
and easy removal of the burner assemblies.
To remove: Allow the burner assembly to cool. Lift up
cooktop. Grasp the burner assembly and rotate it sfightly
toward the left to release the two tabs on the assembly.
Then lift the assembly and pull toward the back of the
cooktop until the air shutter ends on the assembly release
from the valves.
To replace: Insert the air shutter ends on the burner
assembly over the valves and lower the assembly into
place. Be sure to secure the two tabs on the burner
assembly into the two slots on the burner support bracket
which is mounted to the burner box bottom. (NOTE: If the
tabs are not properly inserted into the slots, the assembly
may rock and the burners may not light properly.)
The porcelain on the burner is durable but over time and
with use may gradually lose its shine.
The sealed surface burners are secured to the cooktop
and are NOT designed to be removed by the consumer.
Select models feature one or two special SUPER HIGH
SPEED sealed burners located at the right-front and
left-rear. Use these burners to quickly bring water to a boil
and when using larger pans. See information on rating
plate, located on the lower range front frame behind the
broiler door or lower panel, to determine if your appliance
features these burners.
Clean burner cap after each use especially if a spillover
occurs. A soiled burner may result in improper ignition or
an uneven flame. When cleaning the sealed surface
burner, use care to prevent damage to the ignitor. If a
cleaning cloth should catch the ignitor, it could be
damaged or broken.
___ Lip
lgnitor
-" Port directly below ignitor
The surface burner will not light if the ignitor is damaged,
broken, soiled or wet. The burner will also not light if the
ports, especially the small port located directly below the
ignitor, are blocked.
NOTE: When one surface burner is turned to the LITE
position, all four ignitors will spark. Once the burner lights,
turn the knob to the desired flame size.
iii i!i!ili!iiiii!i!iii!iiiiiii iii!!!ii!i!
Select models feature a fow turn down simmer burner
located at the right front position. Use this burner to keep
foods warm, melt chocolate or gently simmer sauces,
soups or stews. Check the rating plate (see front cover for
location) to determine if your range is equipped with this
feature.
