Table 2: Rear Panel VP-4x4xl 4x4 UXGA / Audio Matrix Switcher Features

# Feature
18 INPUT HD15F Connectors
19 AUDIO INPUTS Terminal
Block Connectors
20 OUTPUT HD15F Connectors
21 AUDIO OUTPUTS Terminal
Block Connectors
22 FLASH PROG. Button
23 RS-485 Terminal Block Port
24 RS-232 DB 9F Port
25 REMOTE IR opening
26 DELAY Dipswitches
27 Setup Dipswitches
28 Power Connector with Fuse

4.1 Using the IR Transmitter

You can use the RC-IR2 IR transmitter to control the machine via the built-in
IR receiver on the front panel or, instead, via an optional external IR receiver
The external IR receiver can be located 15 meters away from the machine.
This distance can be extended to up to 60 meters when used with three
extension cables
Before using the external IR receiver, be sure to arrange for your Kramer
dealer to insert the internal IR connection cable
that fits into the REMOTE IR opening on the rear panel.
Connect the external IR receiver to the REMOTE IR 3.5mm connector.
1 Covered by a cap. The 3.5mm connector at the end of the internal IR connection cable fits through this opening
2 Optional. Can be used instead of the front panel (built-in) IR receiver to remotely control the machine (only if the internal
IR connection cable has been installed)
3 Model: C-A35M/IRR-50
4 Model: C-A35M/A35F-50
5 P/N: 505-70434010-S
6
Your UXGA / Audio Matrix Switcher
Connects to the VGA/XGA video sources (from 1 to 4)
Connects to the balanced stereo audio sources (from 1 to 4)
Connects to the VGA/XGA video acceptors (from 1 to 4)
Connects to the balanced stereo audio acceptors (from 1 to 4)
Push in for "Program" to upgrade to the latest Kramer firmware (see
section 8), or release for Normal (the factory default)
Pins B (-) and A (+) are for RS-485; Pin G (Ground) may be connected to
the shield of the cable if desired (see the PINOUT in Figure 7)
Connects to the PC or the Remote Controller
1
Connects to an external IR receiver unit for controlling the machine via
an IR remote controller (instead of using the front panel IR receiver)
Dipswitches for setting the delay time
Dipswitches for setup of the unit (DIP1, DIP 2 and DIP 3 are for setting
the machine #; DIP 4 is for RS-485 Termination)
AC connector enabling power supply to the unit
4
.
Function
5
with the 3.5mm connector
KRAMER: SIMPLE CREATIVE TECHNOLOGY
