Connecting the VP-4x4xl 4x4 UXGA / Audio Matrix Switcher

6 Connecting the VP-4x4xl 4x4 UXGA / Audio Matrix Switcher
This section describes how to:
Connect the VP-4x4xl rear panel (see section 6.1)
Connect a balanced stereo audio input/output (see section 6.2)
Connect the VP-4x4xl to a controlling device via RS-232 (see section 6.3)
Connect several VP-4x4xl machines (see section 6.4)
Set the dipswitches (see section 6.5)

6.1 Connecting the VP-4x4xl Rear Panel

1
the VP-4x4xl, as illustrated in the example in Figure 2, do the
To connect
2
following :
1. Connect up to four VGA/XGA computer graphics sources to the HD15F
INPUT connectors (from INPUT 1 to INPUT 4).
2. Connect up to four balanced
audio source of the computer
connectors (from 1 to 4).
3. Connect the four OUTPUT connectors to up to four VGA/XGA video
acceptors (for example, displays).
4. Connect the four AUDIO OUTPUT terminal block connectors to up to
four balanced stereo audio acceptors
audio amplifiers with speakers).
5. Set the dipswitches (see section 6.5).
6. If required, set the switching delay time (see section 6.6)
7. As an option, you can connect a PC and/or controller to the RS-232 port
(see section 6.3) and the RS-485 port (see section 6.4).
8. Connect the power cord
1 You do not need to connect all inputs and outputs
2 Switch OFF the power on each device before connecting it to your VP-4x4xl. After connecting your VP-4x4xl, switch on its
power and then switch on the power on each device
3 See section 6.2
4 Alternatively, you can connect a separate audio source (as shown for input 1 in Figure 2), or no source at all
5 We recommend that you use only the power cord that is supplied with this machine
8
3
stereo audio sources (for example, the
4
) to the AUDIO INPUT terminal block
3
(for example, balanced stereo
5
.
