Table 1: Front Panel VP-4x4xl 4x4 UXGA / Audio Matrix Switcher Features

# Feature
1 IR (Infra-Red) Receiver
2 POWER Switch
3 SELECTOR IN Buttons Select the input to switch to the output
4 SELECTOR OUT
Buttons
5 ALL Button
6 OFF Button
7 STATUS IN
7-segment
Display
8 STATUS OUT
Labels
9 STATUS OUT
Labels
10 STATUS IN
7-segment
Display
11 VID Button
12 AFV Button
13 AUD Button
14 STO Button
15 RCL Button
16 TAKE Button
17 LOCK Button
1 The SELECTOR IN and OUT buttons also store/recall the input/output configurations (see section 7.5)
2 For example, press ALL and then Input button # 2 to connect input # 2 to all the outputs
3 Refer to section 7.1
4 The VID button is illuminated when in breakaway mode and actions relate to video
5 The AUD button is illuminated when in breakaway mode and actions relate to audio
6 For example, press STO and then the Output button # 3 to store in Setup # 3
7 When in the CONFIRM mode, the TAKE button illuminates
Your UXGA / Audio Matrix Switcher
Signals from the remote control transmitter illuminate the LED
Illuminated switch for turning the unit ON or OFF
When a signal is detected, the input button illuminates in green
Select the output to which the input is switched
Pressing ALL before pressing an input button connects that input to all
2
outputs
Pressing OFF after pressing an output button disconnects that output from the
inputs. To disconnect all the outputs, press the ALL button and then the OFF
button
Displays the selected video input switched to the output (marked above each
input). Also displays the number of IN and OUT ports
Identifies a cross point between each video output to which the video input
displayed below it is connected
Identifies a cross point between each audio output to which the audio input
displayed below it is connected
Displays the selected audio input switched to the output (marked above each
input). Also displays the firmware version number and the MACHINE #
4
When illuminated actions relate to video
When illuminated, the audio channels follow the video channels. The button is
illuminated when the AFV mode is selected
5
When illuminated actions relate to audio
Pressing STO (STORE) followed by an output button stores the current
6
setting
Pressing RCL (RECALL) followed by an output button displays a stored
setup. Pressing the RCL button again implements the new status
Pressing TAKE toggles the mode between the CONFIRM mode
ONCE mode (user confirmation per action is unnecessary). When in
CONFIRM mode, actions are confirmed by pressing the TAKE key
Disengages the front panel switches
Function
1
3
3
7
and the AT
5
