4

BATTERY CHARGING

D Rapid charging with the BC-121N+AD-106
The optional BC-121N allows up to 6 battery packs to be
charged simultaneously.
The following items are additionally required.
• Six AD-106 charger adapters
• An AC adapter (BC-157) or the DC power cable (OPC-656)
AC adapter
(Purchase
separately)
DC power cable (OPC-656)
(Connect with the DC power
supply; 13.8 V/at least 7 A)
20
Transceiver
Turn power OFF
Battery
pack
AD-106 charger
adapters are installed
in each slot.
See the instruction manual
for details of the charger LED
indication, operation, etc.
IMPORTANT: Battery charging caution
Ensure the guide tabs on the battery pack are correctly
aligned with the guide rails inside the charger adapter.
(This illustration is described with the BC-160.)
Guide rail
Tabs
