Icom IC-F3022T Instruction Manual page 10

2
PANEL DESCRIPTION
SCAN ADD/DEL (TAG) KEY
➥ Push to add a channel to, or delete it from the current scan
list.
• When a channel is added to the current scan list, the display
shows "SCAN ON." When a channel is deleted from the current
scan list, the display shows "SCAN OFF." After showing "SCAN
ON" or "SCAN OFF," the display shows the current scan list text.
➥ You can add a channel to, or delete it from the scan list
after selecting the list.
1. Hold down for 1 sec. to display the current scan list, and then
push [CH Up] or [CH Down] to select a desired list.
2. Push this key to add a channel to, or delete it from the selected
list.
• When a channel is added to the selected scan list, the display
shows "SCAN ON." When a channel is deleted from the
selected scan list, the display shows "SCAN OFF."
3. Hold down this key for 1 sec. to exit the scan list selection
mode.
➥ Push this key while a scan is paused on a channel, except
for primary or secondary channel, and then the channel is
deleted from the scan list.
• Depending on the setting, the deleted channel is added to the
scan list again after the scan is cancelled. (Nuisance Delete
function)
MR-CH 1/2/3/4 KEYS
Push to select memory channels 1 to 4 in the operating zone
directly.
6
WIDE/NARROW KEY
Push to toggle the IF bandwidth between wide, mid* and nar-
row.
• The wide passband width can be selected from 20.0 or 25.0 kHz
using the CS-F3020/F5010/F5020
eration only) Ask your dealer for details.
* Depending on the presetting, the mid width may not be selectable.
Ask your dealer for details.
PRIO A/B KEYS
➥ Push to select Priority A or Priority B channel.
➥ Push and hold [Prio A (Rewrite)] or [Prio B (Rewrite)] for 1
sec. to reassign the operating channel to Priority A or Pri-
ority B channel.
MONI KEY
Mute and release the CTCSS (DTCS) or 5-tone squelch mute.
Open any squelch/deactivate any mute while pushing this key.
LOCK KEY
➥ Push and hold for 1 sec. to electronically lock all program-
mable keys except the following:
[Call] (incl. Call A and Call B), [Moni], [Emergency],
[Surveillance], [Siren], [Lone Worker] and [OPT 1/2/3].
➥ Push and hold for 1 sec. again to turn the lock function
OFF.
HIGH/LOW KEY
Push to select the transmit output power temporarily or per-
manently, depending on the pre-setting.
• Ask your dealer for the output power level for each selection.
. (PMR op-
cloning software
