■ Power supply connection

Make sure the repeater's power switch is turned OFF
when connecting a DC power cable.
R WARNING! Voltages greater than 16 V DC will
damage the repeater. Check the source voltage be-
fore connecting the power cable.

INSTALLATION AND CONNECTIONS

■ Mounting the repeater

D Using the supplied handles

The handles are convenient for mounting the repeater
into a 19 inch rack. The handles can be installed on
the repeater's front panel.
q Attach the handles to both sides of the repeater's
front panel with the spacers, then tighten the
screws.
Handle
w The completed installation should look like this.
