EUROCOM Notebook User Manual page 123

6. Select the CD-ROM/DVD-ROM as the first device in the "Boot priority
order" by pressing the <Shift> and <+> keys to move the CD-ROM/DVD-
ROM to the top of the order.
Main Advanced
Boot priority order:
1: IDE 1:
2: IDE 0:
3: PCI SCSI: FT TX
4: USB FDC:
5: PCI LAN:
6:
7:
8:
Excluded from boot order:
: USB HDD:
: USB CDROM:
F1 Help
Esc Exit
7. Make sure that the computer is connected to the AC power source, and
press F10 to save the changes, and exit the BIOS.
8. As the computer boots up you will see the screen below if no disk array is
defined (press the Tab to enter the utility).
VIA Technologies, Inc.VIA VIA8237 Series SATA RAID BIOS Setting Utility V4.93
Copyright(C) VIA Technologies, Inc. All rights reserved.
237R493.ROM - FOR RAID
Scan Devices, Please wait...
Raid
Array 0 - RAID 0
Serial_CH0 Master:
Serial_CH0 Master:
Press < Tab > Key into User Window!
PhoenixBIOS Setup Utility
Security Boot Exit
Item Specific Help
QSI CD-RW/DVD-ROM SBW242C Keys used to view or
configure devices:
Ary 1 Up and Down arrows
select a device.
<+> and <-> moves the
device up or down.
<f> and <r> specifies
the device fixed or
removable.
<x> exclude or include
the device to boot.
<Shift + 1> enables or
disables a device.
<1 - 4> Loads default
boot sequence.
Select Item -/+ Change Values F9
Select Menu Enter Select Sub-Menu F10
Normal
FUJITSU MHT2060BH
FUJITSU MHT2060BH
Setup Defaults
Save and Exit
Modules
Figure 7 - 9
Boot Menu (BIOS)
Figure 7 - 10
VIA RAID BIOS
Boot Screen
RAID Setup 7 - 23
7
