Truncate—Truncate the attribute.
Attribute Settings
You can create new attribute schemas. See Attribute Editor Panels below for information about
different datatypes' fields. Once you create a set of attributes, they remain available for re-use as a
schema, or collection of attributes. To identify schemas, enter the following fields:
Label— A unique, mandatory identifier for the collection of attributes.
Description— A text description of the entity.
Click New to create or select an attribute in the displayed tree and click Edit to open an editor
where you can create or modify attributes. Select an attribute and click Remove to delete it from
the list.
Attribute Editor Panels
The following panels appears, depending on the attribute type selected from the pick list. The
fields in the editor depend on this selection. Available types include Boolean, Coded Value, Date,
Decimal, IP Address, Integer, Long, Inventory Reference, and String. The following fields appear
for each of these types (omitting redundant fields):
NOTE:
Configure the data type of an attribute before you save a task. After attributes are in Scripts, you cannot
change the data type.
Boolean
Default Value—Check for True.
Coded Value
Default Coded Value—Enter the default coded value. If an attribute a Coded Value then enter
valid values in the format of NUMBER:Display Label. For example:
10:Hello World
20:Hello Moon
Without this pattern a validation error appears. Coded values become a Drop Down (Combo
Selection) at runtime containing the Display labels within it (like Hello World, Hello Moon).
Selecting one gives the script the numeric value (If users select Hello World, the value the
script gets is 10)
The default appears by default in this list of alternatives. Enter any other alternatives below
this field in the Valid Values.
Valid Values—Enter a valid value in the line above the table of valid values, then click the green +
to add the value entered to the list. Click the Remove icon (the red -) to delete a selected
value. These must be formatted like the Default Coded Value.
