Dell OpenManage Network Manager Client Manual page 258

Apply to Series — Check to enable on composite attributes only. Checking this applies the
threshold to individual elements within the series. When it is unchecked, the threshold
applies only to aggregate measurements (the overall value of the series), not individual
elements within the series.
For example; a Key Metric monitor for CPU utilization on a device with two CPUs actually
monitors both CPUs. When unchecked, the threshold applies to the average of both CPUs,
when checked, the threshold applies to each individual CPU.
When you check this, you can also apply thresholds to regular expressions. This is useful to monitor
components within components, for example cores within a CPU.
Click Apply to preserve your edits, or Cancel to abandon them.
The threshold interval editor pops up when you select the Add button or the Edit icon to the right
of a threshold's row in the threshold attribute editor.
This screen contains the following fields:
Name—The identifier for the threshold interval.
Severity—The event severity for crossing this threshold interval (informational/indeterminate/
warning/minor/major/critical)
Color—The color to display threshold interval on graphs.
Lower Boundary—The interval's lower boundary.
Upper Boundary— The interval's upper boundary. May be blank.
Matching String—A Regex matching string.
258
Resource Monitors | Monitoring
Tip
