Introduction, cont'd

Transmission distance

The maximum distance is determined by the output frequency and resolution. The
following table specifies the recommended maximum transmission distances using
STP or FTP CAT 5 cable, terminated with CAT 5 rated connectors.
Recommended transmission ranges at 60 Hz
Video format
640 x 480
800 x 600
1024 x 768
1280 x 1024
1600 x 1200

Features

Four input A/V switcher — Accepts, switches, and transmits RGBHV, component
Buffered monitor output on input 1 — Provides for local monitor output on a
Universal projector control — The TPS150 provides universal projector control via
Skew compensation control — Individual red, green, and blue skew controls
Sharpness control — Provides video equalization with individual low frequency
Audio input level adjustment — Each individual input has a level adjustment via
Audio output volume adjustment and muting — The output has volume control
Control — Switcher control is available through the front panel, an RS-232 port
1-4 TPS150 Switching and Transmission System • Introduction
It is possible to exceed the recommended distance; however, image quality may
be reduced.
We recommend the use of pre-terminated and tested cables. Cables terminated
on site should be tested before use.
Maximum range
500 feet
500 feet
500 feet
300 feet
250 feet
video (Y, R-Y, B-Y), S-video, composite video, and RS-232 serial content.
Accepts and switches unbalanced line level stereo audio.
15-pin HD female VGA connector, enabling a signal to be easily monitored
locally without the need for a separate distribution amplifier.
serial commands entered by the installing technician. Commands are
automatically sent when the input selection or Projector Power buttons are
pressed. The included ICS100 control software makes storing projector or
display control codes easy
adjust for the timing delays commonly encountered when CAT 5, CAT 5e, or
CAT 6 cable is used.
and high frequency adjustments. The low frequency control helps remove
image smearing. The high frequency control restores image sharpness and
detail.
the front panel and RS-232 control. Audio levels are saved for each input and
are automatically recalled when that input is selected.
adjustment via the front panel, RS-232 control, or optional contact closure
panel control.
serial link, and an optional contact closure control panel. Serial control is
provided with the Extron ICS 100 control software and/or a control system
issuing serial commands.
