Video output
Number/signal type ................... 1 VGA/SVGA/XGA/SXGA RGBHV,
Connectors .................................... 1 15-pin HD female
Minimum/maximum levels ...... Analog ....... 0.3V to 1.5V p-p with no
Impedance .................................... 75 ohms
DC offset ....................................... ±5mV maximum with input at 0 offset
Output resolution may vary depending on whether the P/2 DA1
is attached to the computer at startup, and on the type of
computer you are using.
Sync
Input type ..................................... RGBHV, RGBS, RGsB, RsGsBs
Output type .................................. RGBHV, RGBS, RGsB, RsGsBs
Input level ..................................... 2.0V to 5.0V p-p
Output level .................................. TTL ............. 5V p-p
Input impedance .......................... 510 ohms
Output impedance ....................... 75 ohms
Max. propagation delay .............. 18.8 nS
Max. rise/fall time ....................... 4 nS
Polarity .......................................... Positive or negative
General
Power ............................................. USB (5.0VDC, less than 200 mA)
Temperature/humidity .............. Storage -40° to +158°F (-40° to +70°C) /
Rack mount ................................... No
Enclosure type .............................. Plastic clamshell
Enclosure dimensions ................. 0.56" H x 1.25" W x 3.0" D
Shipping weight .......................... 1 lb. (0.5 kg)
Vibration ....................................... ISTA/NSTA 1A in carton
Approvals ..................................... CE, UL, CUL
MTBF ............................................. 30,000 hours
Warranty ....................................... 2 years parts and labor
Part Number
P/2 DA1 USB ............................... 60-319-03
Specifications are subject to change without notice.
Extron Electronics, USA Extron Electronics, Europe
1230 South Lewis Street, Anaheim, CA 92805 Beeldschermweg 6C, 3821 AH Amersfoort
800.633.9876 714.491.1500 FAX 714.491.1517 +31.33.453.4040 FAX +31.33.453.4050
USA The Netherlands
© 2001 Extron Electronics. All rights reserved.
RGBS, RGsB, RsGsBs
offset at unity gain
10% to 90%, non-condensing
Operating +32° to +122°F (0° to +50°C) /
10% to 90%, non-condensing
1.4 cm H x 3.2 cm W x 7.6 cm D
(International Safe Transit Association)
Extron Electronics, Asia Extron Electronics Information
135 Joo Seng Rd. #04-01, PM Industrial Bldg. ExtronWEB
+65.383.4400 FAX +65.383.4664 ExtronFAX
Singapore 368363 24-hour access—worldwide!
User's Guide
™ : www.extron.com
™ : 714.491.0192
P/2 DA1 USB
VGA Line Driver
68-480-02 B
Printed in the USA
01 01
