Extron electronics Scan Rate Indicator SRI 200 Specifications

Specifications — SRI 200 Scan Rate Indicator

Video input

Horizontal frequency .................. 10 kHz to 150 kHz
Vertical frequency ....................... 30 Hz to 200 Hz
General
Power ............................................. 3VDC supplied by 2 internal lithium batteries (Panasonic BR2325 or equivalent),
Temperature/humidity .............. Storage -40° to +158°F (-40° to +70°C) / 10% to 90%, non-condensing
Rack mount ................................... No
Enclosure type .............................. Plastic
Enclosure dimensions ................. 1.0" H x 2.2" W x 3.5" D
Product weight ............................. 0.2 lbs (0.1 kg)
Shipping weight ........................... 1 lbs (0.5 kg)
Vibration ....................................... ISTA/NSTA 1A in carton (International Safe Transit Association)
Listings .......................................... UL, CUL
Compliances ................................. CE, FCC Class A
MTBF ............................................. 30,000 hours
Warranty ....................................... 3 years parts and labor
Specifications are subject to change without notice.
1-2
SRI 200 • Specifications
auto power
Operating +32° to +122°F (0° to +50°C) / 10% to 90%, non-condensing
2.5 cm H x 5.6 cm W x 8.9 cm D
(7.40-111401_010603-D1+)
