PECIFICATIONS

VIDEO INPUT

Number/signal type.................. 1 RGBHV, RGBS, RGsB, component
Connectors .............................. 2 x 5 BNC female (5 BNCs for
Minimum/maximum levels ...... 0V to 2.0V p-p with no offset at unity
Impedance .............................. 75 ohms
Horizontal frequency ................ Autoscan 24 kHz to 100 kHz
Vertical frequency .................... Autoscan 50 Hz to 120 Hz
Resolution range ...................... Autoscan 560 x 384 to 1600 X 1200
Maximum DC offset ................ 2.0V
External sync (genlock) ............ 0.3V to 1.0V p-p
VIDEO PROCESSING
Encoder .................................... 10 bit digital
Digital sampling ...................... 24 bit, 8 bits per color
Colors ...................................... 16.8 million
Horizontal filtering.................... 8 levels
Vertical filtering ........................ 4 levels
Encoder filtering ...................... 4 levels
VIDEO OUTPUT
Number/signal type.................. 1 RGBHV, RGBS, RGsB, or
Connectors .............................. 5 BNC female:
Minimum/maximum levels ...... 0.0V to 1.0V p-p
Impedance .............................. 75 ohms
SYNC
Input type ................................ Autodetect RGBHV, RGBS, RGsB
Output type.............................. RGBHV, RGBS, RGsB
Genlock connectors .................. 1 BNC female: genlock input 1 BNC
Standards ................................ NTSC 3.58, PAL
Input level ................................ 1.5V to 5.0V p-p
Output level ............................ TTL: 5.0V p-p
Input impedance ...................... 600 ohms
Output impedance .................. 75 ohms
Max. input voltage .................. 5.0V p-p
Polarity .................................... Negative
video with 1 buffered loop-through;
1 RGBHV, RGBS, RGsB with 1 buffered
loop-through
RGB/component video input,
5 BNCs for RGB/component video
loop-through)
(1) 15-pin HD female for RGB input,
(1) 15-pin HD female for buffered RGB
loop-through(RGB)
gain
component video;
1 SDI component video
(VSC 900D only)
1 S-video
1 NTSC/PAL composite video
RGBHV/RGBS/RGsB/component video
1 BNC female: SDI component video
(VSC 900D only)
1 4-pin mini DIN female: S-video
1 BNC female: composite video
female: genlock output (terminate
w/75 ohms if unused)
CONTROL/REMOTE — SCAN CONVERTER
Serial control port .................... RS-232/RS-422, 9-pin female D
Baud rate and protocol ............ 9600, 8-bit, 1 stop bit, no parity
Serial control
pin configurations ................ 2 = TX, 3 = RX, 5 = GND,
IR controller module ................ VSC Remote
Program control ...................... Extron's control program for Windows
GENERAL
Power ...................................... 100VAC to 240VAC, 50/60 Hz,
Temperature/humidity .............. Storage -40° to +158°F (-40° to +70°C) /
Rack mount .............................. Yes, with optional brackets
Enclosure type .......................... Metal
Enclosure dimensions................ 1.75" H x 17.5" W x 9.5" D (1U high,
Product weight ........................ 5.6 lbs (2.5 kg)
Shipping weight ...................... 12 lbs (5.45 kg)
Vibration .................................. ISTA/NSTA 1A in carton
Listings .................................... UL, CUL
Compliances ............................ CE, FCC Class A, VCCI, AS/NZS, ICES
MTBF........................................ 30,000 hours
Warranty .................................. 3 years parts and labor
Model
VSC 900 .................................. 60-478-01
VSC 900D ................................ 60-478-02
VSC Remote ............................ 70-206-01
Included Accessories
VSC IR Remote.......................... 70-206-01
BNC termination adapter.......... 26-300-01
SVHSF (1.83 m) ........................ 26-316-02
Optional Accessories
Under desk mounting kit .......... 70-219-01
1U Rack Shelf............................ 60-190-01
SVHSM-BNCF Adapter .............. 26-353-01
RCA (female), BNC (male)
Adapter ................................ 10-264-01
S-video cable 6' (1.83 m).......... 26-316-02
SDI output card ........................ 70-065-02
Specifications are subject to change without notice.
connector
9 = hard-wired IR
Extron's Simple Instruction Set ™
30 watts, internal, auto-switchable
10% to 90%, non-condensing
Operating +32° to +122°F (0° to
+50°C) / 10% to 90%, non-condensing
full rack width) 4.4 cm H x 44.5 cm W
x 24.1 cm D (Depth excludes
connectors and knobs)
(International Safe Transit Association)
Part Numbers
®
(SIS ™ )
