Operation

Important: Always mow with the discharge
deflector installed and in the down position.
DANGER
An uncovered discharge opening will allow
objects to be thrown in an operator's or
bystanders's direction. Also contact with the
blade could occur. Thrown objects or blade
contact can cause serious injury or death.
Never operate the mower with the discharge
deflector raised, removed, or altered unless
there is a grass collection system or mulch
kit in place and working properly.
DANGER
The rotating blades under the mower deck
are dangerous. Blade contact can cause
serious injury or kill you.
Do Not put hands or feet under the mower
or mower deck when the blades are engaged.

Opening the Discharge Gate

Push down on the back of the foot pedal to open
the gate.
1. Push down
2. Foot pedal
3. Gate open

Closing the Discharge Gate

Push down on the front of the foot pedal to close
the gate.
1. Push down
2. Foot pedal
11
Operation
Figure 10
4. Discharge deflector
5. Discharge opening
Figure 11
3. Gate closed
4. Discharge deflector
