Control Parts - KitchenAid KSRS25FGAL00 Parts List

For Models: KSRS25FGWH00, KSRS25FGAL00, KSRS25FGBL00, KSRS25FGBT00
Illus. Part
No. No. DESCRIPTION
1 2200134 Control Box
2 2182150 Tube Barrier,
Thermostat (RC)
3 489214 Screw (3)
4 2149705 Light Switch
5 2161461 Thermostat (FC)
6 2188159 Adaptive Defrost
Control
7 489398 Screw (2)
8 2196003 Tube Barrier,
Thermostat (FC)
9 2161460 Thermostat (R.C.)

CONTROL PARTS

(White) (Almond)
Illus. Part
No. No.
10 2172940 Window
11 2172906 Grommet, Light Bar
12 2161466 Slide, Thermostat
13 489084 Screw (2)
14 2179920 Light Bar (RC)
15 2200096 Cover, Light
16 489290 Screw (2)
17 2162085 Light Socket
18 2172931 Heat Shield
19 527949 Light Bulb
F O R O R D E R I N G I N F O R M A T I O N R E F E R T O P A R T S P R I C E L I S T
(Black)
Illus.
DESCRIPTION No.
20
21
22
23
Lens
24
25
26
27
16
(Biscuit)
Part
No. DESCRIPTION
2200109 Control Box
Harness
2200097 Retainer,
Light Lens
1115375 Clip, Wiring
2200098 P.C. Board
Filter Indicator
2200379 Hole Plug
2200099 Escutcheon,
Control Box
2179921 Light Bar (FC)
2172941 Window
4398077
