KitchenAid KSRS25FGAL00 Parts List page 12

FREEZER DOOR PARTS
For Models: KSRS25FGWH00, KSRS25FGAL00, KSRS25FGBL00, KSRS25FGBT00
(White)
Illus.
No.
10
11
12
13
14
15
16
17
F O R O R D E R I N G I N F O R M A T I O N R E F E R T O P A R T S P R I C E L I S T
(Almond)
Part
No. DESCRIPTION
1 Freezer Door
(Includes #8
And Dispenser
Front Parts)
2186519W White
2186519N Almond
2186519B Black
2186519T Biscuit
2 Retainer, Insert
2194777W White
2194777N Almond
2194777B Black
2194777T Biscuit
3 End Cap (2)
2194778W White
2194778N Almond
2194778B Black
2194778T Biscuit
4 489463 Screw
5 3400012 Screw
6 3400852 Screw
7 2171070 Shelf Bin (4)
8 Door Gasket,
Magnetic (Service)
2159074 Mist Beige
2159082 Black
9 Insert, Handle
2173825 White
2173828 Almond
2173829 Black
2186863T Biscuit
2195931 Trim, Door Shelf
2156006 End Cap
488500 Screw
2180229 Wire Harness
2182132 Door Closer,
Upper Cam
2154473 Connector
489420 Screw
Bracket, Door Stop
2195950 Black
2195952 Chrome
12
(Black) (Biscuit)
4398077
