KitchenAid KSRS25FGAL00 Parts List page 14

For Models: KSRS25FGWH00, KSRS25FGAL00, KSRS25FGBL00, KSRS25FGBT00
Illus. Part
No. No. DESCRIPTION
1 Housing, Dispenser
(Not Serviced)
2 489101 Screw
3 2194719 Retainer, Levers
4 2180209 Spring, Torsion
5 2180210 Pin
6 2180205 Door, Ice
7 2180208 Door Mechanism
Assembly
8 2180223 Mechanism Delay
9 Grille, Overflow
2180323 White
2180324 Almond
2180325 Black
2186860 Biscuit
10 2180225 Water Fitting
Assembly (Includes
Water Tube)
DISPENSER FRONT PARTS
(White) (Almond)
Illus. Part
No. No.
11
2180259 White (White
2180260 Almond (Almond
2180261 Black (Storm
2186850 Biscuit (Almond
12 2180224 Guide, Ice
13 2180200 Lamp Holder
14 2162361 Switch (4)
15 2183771 Bracket, Control
16 3406124 Bulb, Light
17
2180268 White (White
2180269 Almond (Almond
2180270 Black (Storm
2186852 Biscuit (Almond
F O R O R D E R I N G I N F O R M A T I O N R E F E R T O P A R T S P R I C E L I S T
(Black)
Illus.
DESCRIPTION No.
Lever, Ice 18
Dispenser
Shadow Pad) 19
Shadow Pad)
Grey Pad)
20
Shadow Pad)
21
22
23
Lever, Water
Dispenser
Shadow Pad)
Shadow Pad)
Grey Pad)
25
Shadow Pad)
14
(Biscuit)
Part
No. DESCRIPTION
2180236 Switch Assembly
(Also Order
Item #19)
Overlay, Front
Cover
2186515W White
2186515N Almond
2186515B Black
2186515T Biscuit
2180240 Wire Assembly
Front Cover,
Housing
(Not Available,
Order #23)
489000 Screw
Front Cover
Assembly
(Includes Items
18, 19, 20 & 21)
2186511W White
2186511N Almond
2186511B Black
2186511T Biscuit
2195051 Strain Relief
4398077
