KitchenAid KSRS25FGAL00 Parts List page 8

MOTOR AND ICE CONTAINER PARTS
For Models: KSRS25FGWH00, KSRS25FGAL00, KSRS25FGBL00, KSRS25FGBT00
(White)
Illus.
No.
10
11
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
37
38
39
40
42
44
45
46
F O R O R D E R I N G I N F O R M A T I O N R E F E R T O P A R T S P R I C E L I S T
(Almond)
Part
No. DESCRIPTION
1 2183726 Bracket, Motor
2 2155263 Motor, Dispenser
3 2152713 Soleniod Assembly
4 2149100 Guide, Solenoid
7 2169490 Wiring Assembly,
Ice Dispenser
8 489399 Screw
9 983663 Coupling, Motor
489478 Screw
2162085 Socket, Light
2196091 Ice Container
983668 Coupling, Conveyor
1118480 Stop, Cone
1119074 Feeder Cone
1119005 Spacer, Step (3)
1119007 Spacer, Flat (2)
1119006 Blade, Rotary
1119012 Blade, Rotary
1119013 Blade, Rotary
489235 Washer, Plain
1119009 Blade, Fixed (2)
2157405 Block, Blade
489229 Roll Pin
2181955 Conveyor
2171681 Drum
1118470 Drive Bar
2171682 Floating Baffle
1119018 Nut, Bearing
2155231 Control Arm
1119020 Spring, Return
1119021 Retainer Clip, Rod
488886 Screw
2180348 Housing, Crusher
1119017 Deflector, Ice
489234 Washer, Plain
489236 Retainer Ring
2152021 Sleeve−Auger
2171708 Front Cover,
Ice Container
527949 Light Bulb
2171706 Light Lens,
Dispenser
8
(Black) (Biscuit)
4398077
